Clear Quartz Halogen Infrared Heater Lamp for Food Baking

Hefei Quickly Electric Co., Ltd.
Clear Quartz Halogen Infrared Heater Lamp for Food Baking thumbnail-1
Clear Quartz Halogen Infrared Heater Lamp for Food Baking photo-1
US$ 1 - 200 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Brand Name:
KKL
Color:
Other, transparent, Yellow, white coated
Material:
Other, quartz, Quartz, high-calss imported quartz sand and heating filament
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name KKL
Color Other, transparent, Yellow, white coated
Material Other, quartz, Quartz, high-calss imported quartz sand and heating filament
Certification Other, CE, CE, CE approved by EMC



Infrared heating lamp



Infrared heating is a kind of radiation heating. It spreads by a kind of infrared radiation

(light)-- infrared light from material in the form of molecular (atomic) resonance absorption,

so as to achieve the purpose of heating. It can be applied in many fields such as the

heating process of industry coating, plastic forming, automotive industry, glass making,

spinning, solar PV, food baking, drying of printing inks, quick drying of primer and paint

on furniture, printed circuit, and so forth.



Specifications:



  • Gold-coated or infrared quartz
  • With gold reflective side, can save more than 50% energy
  • Lifespan: 5000 hours
  • Certification: CE
  • Suitable for new type quartz tube heaters
  • Voltages: 110, 220 or 380V or other voltage grades needed by users
  • Power: 0.3 to 6kW
  • Length: 300 to 3000mm
  • Outer diameter: 10-18mm
  • ·  Surface temperature of heater divides into three grades:
  • o Low temperature: 400 to 600℃
  • o Mid temperature: 600 to 800℃
  • o High temperature: 800 to 1000℃
  • Wavelength:1.0-1.4um
  • Reaction time:1S





 Advantages:



  • Process, design and products can be customized
  • · 5000 hours lifespan
  • · CE certification
  • · Small order accepted
  • · Science,energy saving,safety and environmental protection
  • · Single-ended wire
  • · Very short time of heating and cooling
  • · Reasonable price



clear quartz halogen infrared heater lamp for food baking



Applications of infrared quartz heater part:

01.Paint drying

02.PET bottle blowing and laminating

03.Paper drying

04.Wood drying and preheating before painting

05.Plastic softening and synthesis cable production

06.Industrial production oven

07.Car painting

08.High temperature disinfection

09.Food heating

10.Glass Lamination

11.welding



FAQ

1.About Quickly

Holding 10 Years of experience established in 2005, Hefei Quickly Electric Co. Ltd focuses on creating fast, efficient and

accurate infrared lamps for customers. We have developed an infrared heating tube with patents and excellent quality,

leading the quality standards and technical level of this product in the world.Through our continuous R&D of products,

improving technology and reducing costs, we specialized in the field of infrared heating broader.



2.Can you make custom size lamp?

All of our lamps are customized,the size,voltage and wattage,reflector and etc.Just tell me what you need,or send us

drawing.We will give you the lamp you want.



3.How long about the lamp life time?

Short wave infrared lamp lifespan 5000 hours,Medium wave infrared lamp lifespan 20000 hours,carbon fiber lamp lifespan

10000 hours,fast medium wave lamp lifespan 10000 hours(man-made and improper operation excluded)



4.How about the after Sales?

Every lamp will tested by our QC department before shipping.If the lamps have damage in transit or the life time less than

 we guaranteed(man-made excluded}.We will send you new lamps for replace.



5.What is the payment term?

We accept T/T,Paypal,Western Union,this can be negotiated.



6.How about the delivery time?

10-15 days after receiving the deposit



7.How about the package?

Outside packed in wood and inside packed in soft EPE, we can do package according to your design.



8.How to contact Quickly?

Skype: cathy520zjf

QQ:2764732842

Mobile: 86-13767487075

Phone:86-551-65208999-604

WhatsApp: 13757487075
