♦The film greenhouse technicial date
Specification | Index |
Product type | UV Film |
Nominal Thickness | 150, 180, 200 micron |
Light Transmission (%) | >88 % |
Temperature | -15 ℃—60 ℃ |
Tensile Strength | ≥30MPa |
Tear Resistance | ≥580%
|
♦The film greenhouse specs
Specification | Index |
Cover | inflatable film |
Style | Dome |
Framework | Hot dipped galvanized steel |
Wind load(KN/m2) | 0.60 |
Snow load(KN/m2) | 0.50 |
Constant load plus(Kg/m2) | 15 |
Impact strength | 850J/m |
Light Transmission | >88% |
Heat Conductivity | 0.2W/(m.K) |
Range of temperature | -15°C ~60°C |
We can provide the parameters above depends on the local climate.
Size | Index |
Width(m) | 9.6m |
Length(m) | 40m |
Height(m) | 6m |
And the size can be manufactured as your requests.
The commeicial plastic greenhouse is can ben plastic, polycarbonate, glass, solar etc. greenhouse. These commercial gresnhouse support the system like cooling system, heating system, ventilation system, irrigation system etc. The feature is as follow:
1. Suitable and pratical for hydroponic system and aquaponics
2.Manually and auto control system
3.Good anti-UV, anti-wind, anti-drip etc.
4.Befor and after service. (totally design by professional engineer)
Plastic film greenhouse is suitable for tropical place. It is advantage in practical and suitable used.
We MYXL Greenhouse can accord to your local climate condition to design the most suitable and practical plastic film greenhouse for you.
At the same time, all the specification can be customized. Such anti-UV, anti-wind, waterproof, light transmission index.
Specification | Index |
Cover | three layers co-extrusion pep film, seven layers co-extrusion PO film, Inflatable double layers film greenhouse |
Single layer Film | 80/100/120/150/180/200 micron |
Double inflatable film | inlayer 150micron, outer 200micron |
Style | Arch/Dome |
Framework | Aluminum / Hot dip galvanized steel |
Size | Large |
Width(m) | 6, 7, 8, 9…(customized) |
Length(m) | 10, 20, 30... (customized) |
Height(m) | 2.5-12…(customized) |
Wind load(KN/m2) | 0.35 |
Snow load(KN/m2) | 0.25 |
Rainfall(mm3/h) | 140 |
All the specification of index can be customized .
Here is the most popular size for agriculture greenhouse.
| Size | Index |
| Width(m) | 9.6m |
| Length (m) | 40m |
| Height(m) | 6m |
NO.1 PEP film, (anti-UV, anti-drip, anti- dripping)
NO.2 Easy assemble
NO.3 Manual or automatic operation
NO.4 installation supervision
Who we are
No.1Our factory
No2.Focus on engineering design before and after service
No3. Focus on commercial greenhouse research and development
No4. Focus on upgrading greenhouse equipment
>View more" href="http://xlonghouse.en.china.cn/productgrouplist-802967388/Greenhouse_Equipment.html"> >>View more
sun shade net hydroponic system
1.shade rate:30-90% for different kinds of planting
lor:any color is available 2.system supervision
Ventilation system cooling system
1.good at natural ventilation 1. kinds of frame sizes for choice
2. system supervision 2. high absorbability, high water resistant
>View more " href="http://xlonghouse.en.china.cn/productgrouplist-803060884/Complementary_System.html">>>View more
