ground circle pile solar mounting bracket
This solar pipe mounting bracket is new developed by Frontier, which more suitable for Japan market. The components are less than normal galvanized steel solution. Ground screw pile is replace by the kuimaru pile. Fasteners are scaffolding couplers. These help save much installation time and labor cost. The solar pipe mounting bracket has done more than 5MW in Japan.
| Wind load | 30m/s~55m/s |
| Basic Wind Pressure | 0.5-1.4 KN/m2 |
| Product Material | Q235 Hot-galvanized steel with thickness>65um |
| Fasten Material | Stainless steel (304) |
| Tilt angle | 5~20degree |
| Ground pile | φ48.6*1500*2.4mm |
| The distance from lowest point of panel to ground | 300↔500 mm |
1. Scaffolding couplers can revise inclination of pile easy.
2. Save installation time, the whole structure doesn’t have strict demands for accuracy of installation.
3. The pile is special made, it has solid head. So it is also suitable for sand soil.
Trial Installation:
Frontier, starts in 2005, is the first solar racking system developer in China, who committed to solar racking system R&D, producing and marketing for about 10 years. We were the OEM for Sunpower, and are one of the largest rooftop solar racking system supplier in Japan and Australia now.
Frontier persists in taking the path of specialization, scale and internationalization development. We import the international advanced technology equipment for manufacturing , assembling and testing. Frontier solar racking system is with own patents. The dynamic wind resistance reliability of our racking system can up to 270km/h. Therefore, superior product quality with more than25years' durability and perfect after-sale service have earned us a high reputation in PV industry worldwide.
1. Quick response: the inquiry will be replied with 24 hours.
2. Customized design: we are professional solar racking system solution designer and manufacturer, with 10 years' solution database. 3. Good quality: everything component is strictly quality controlled in the factory, strong and safe, and comply with AS/NZS 1170. 4. Easy installation: Frontier circle pile solar mounting bracket
are greatly simplified and pre- installed without welding onsite, which save a lot installation time.
How to buy your ideal products?
A: Providing the information of your projects required, then we will make the most suitable solution and products.
How to pay?
A:TT will be more appreciated. 30% deposit after oder confirmed, 70% before shipment.
What is the delivery time?
A: It depends on order quantities. Generally, the delivery time will be within 15 to 30 days.
How to pack the products?
A: We use standard package, carton boxes, wooded pallet and steel pallet. If you have special
package requirements, we will pack as required. The fees are negotiable.
How to install after the goods arriving destination?
A: We will provide detailed illustrations to you. If it is necessary, we will send technicians to help you. However, the visa fee, air tickets, accommodation, wages will be paid by buyers.
Dear Buyer,
In order to help you get the exact quotation, some information are needed for this circle pile solar mounting bracket , pls offer the following info.,
1. The solar panel dimension: (L*W*H)?
2. Solar panel power each: (W)?
3. The tilt required: degree?
4. Wind load and snow load required: ?
5. Solar panel layout required: ?
6. The distance between the lowest point of panel and ground: ?
