2016 Multi-purpose Solar Energy System With Storage/ Solar Energy Storage Systems

Shanghai Frontier Energy Technology Co., Ltd.
2016 Multi-purpose Solar Energy System With Storage/ Solar Energy Storage Systems thumbnail-1
2016 Multi-purpose Solar Energy System With Storage/ Solar Energy Storage Systems thumbnail-2
2016 Multi-purpose Solar Energy System With Storage/ Solar Energy Storage Systems photo-1
2016 Multi-purpose Solar Energy System With Storage/ Solar Energy Storage Systems photo-2
US$ 1 - 2 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
Frontier
Model Number:
FES8030B
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shanghai, China
Brand Name Frontier
Model Number FES8030B
Specification Normal
Application Home
Output Voltage (V) AC100-240V
Load Power (W) 3000W
Solar Power (W) 2400W
Work Time (h) Depends
Specifications

3kw hybrid solar energy storage unit



A Solar Energy Storage System with Solar&AC charger, Li-ion Battery with Advanced BMS, Pure Sine Wave Inverter with UPS Function and Other Control Circuit Modules.



Main Parameters As Below.

1. Charging: Solar MPPT-2400W and AC 1600W;

2. AC output: 2000W/3000W(90V-260V),pure sine wave;

3. Li-ion battery: 52V6630Wh;

4. UPS function

5. Optional WiFi/WLAN communication port

6. On/Off gird work

7. Touch LCD display screen

Clearn energy portable high capacity solar battery energy storage system with built-in li-polymer battery 6.5kWh solar power supply
All-in-one ESS (Energy Storage System)
Model No.FES3215BFES4020BFES6530BFES8030B
Battery
Battery Capacity3.2kWh4.0kWh6.5kWh8.0kWh
Output
Rated Output Power1500W2000W3000W
Peak Output2250W3000W4000W
Output Voltage100/110/120V & 220/230/240V
Output Frequency50/60Hz±0.5Hz
Overload Ability120%<load<130% @10min
130%<load<150% @10s
UPS FunctionYes
On/off GridOff GridOn & Off Grid
Max Efficiency92%(>70% Load)
AC Charge
Input Voltage88~264Vac
Power Factor≥0.94(full load)≥0.95(full load)
Input Frequency50/60Hz±0.5Hz
Max Charge Power600W2400W
Max Efficiency>92%
PV Charge
Max Input Power1200W1500W2400W
Start-up Voltage75Vdc
MPPT Amount2
MPPT Input Voltage75~140Vdc
Max Input Voltage150Vdc
MPPT Efficiency99.50%
Max Efficiency>96%
Solar Charing ModelMPPT
General
Working ConditionRelative Humidity:5%~90%
Temperature:0~45℃
Product Dimension580*300*600mm779*350*912mm
Packing Dimension657*375*645mm880*525*1080mm
Net Weight47Kg59Kg135Kg157Kg
Gross Weight50Kg62Kg160Kg185Kg
Note: 110V AC output power for PS6530B & PS8030B is 2000W

 2016 multi-purpose solar energy system with storage/ solar energy storage systems

2016 multi-purpose solar energy system with storage/ solar energy storage systems

2016 multi-purpose solar energy system with storage/ solar energy storage systems
2016 multi-purpose solar energy system with storage/ solar energy storage systems

Product pictures

 2016 multi-purpose solar energy system with storage/ solar energy storage systems

Packaging & Shipping

One set in one carton

Net weight: 135Kg per set

Gross weight: 160Kg per set

 2016 multi-purpose solar energy system with storage/ solar energy storage systems

Engineering Case

2016 multi-purpose solar energy system with storage/ solar energy storage systems



Certifications&paten

 2016 multi-purpose solar energy system with storage/ solar energy storage systems
