Steel Wire Rope Hydraulic Press Machine
US$ 5,000 - 100,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Model Number:
XT-100, XT-100
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
2014 Hot Sale High Quality Hydraulic Steel Wire Rope Press MachineUS$ 5,000 - 100,000MOQ: 1 Set -
Factory Outlet 800t Hydraulic Steel Wire Rope Press Machine of High QualityUS$ 5,000 - 100,000MOQ: 1 Set
-
800t Hydraulic Steel Wire Rope Press Machine of High QualityUS$ 5,000 - 100,000MOQ: 1 Set
-
2015 Top Qualtiy Hydraulic Steel Wire Rope Sling Press MachineUS$ 5,000 - 100,000MOQ: 1 Set
-
2014 Top Qualtiy Hydraulic Steel Wire Rope Sling Press MachineUS$ 5,000 - 100,000MOQ: 1 Set
Place of Origin
Shandong, China
Model Number
XT-100, XT-100
Steel Wire Rope Hydraulic Press Machine
Product Description
1.Steel Wire Rope Hydraulic Press Machine
2. High junction strength and large working load limited
3. excellent cauterization resistance
4. advanced procession and efficiency
5. good solution to rigging works with limited working space
6. widely used in mine, metallurgy, wharf, railway, electrics, steel, transportation and so on
7. save wire rope cost and ensure the exact length
XT-100 Specification:
| Mode NO. | XT-100 | XT-200 | XT-300 | XT-350 | XT-500 | XT-800 | XT-1000 |
| Max press power(KN) | 1000 | 2000 | 3000 | 3500 | 5000 | 8000 | 10000 |
| Max wire rope diameter(mm) | 13 | 20 | 24 | 26 | 32 | 42 | 52 |
Max working pressure(Mpa) |
28 | 28 | 58 | 28 | 28 | 28 | 28 |
| Max piston movement(mm) | 78 | 78 | 80 | 80 | 120 | 180 | 180 |
| Power(KW) | 4 | 4 | 4 | 5.5 | 11 | 15 | 18 |
| Voltage(HZ) | 50 | 50 | 50 | 50 | 50 | 50 | 50 |
| Total length(mm) | 1200 | 1200 | 1200 | 1200 | 1600 | 2000 | 2350 |
| Total width(mm) | 500 | 600 | 650 | 650 | 680 | 1000 | 1250 |
| Total height(mm) | 1150 | 1220 | 1250 | 1250 | 1800 | 2000 | 2250 |
| up speed(mm/sec) | 8 | 6.5 | 4.5 | 4.8 | 4.5 | 5 | 3.7 |
| down speed(mm/sec) | 10 | 8 | 4.5 | 7.8 | 8 | 8 | 7.5 |
| Net weight(kg) | 900 | 1000 | 1000 | 1000 | 3000 | 5400 | 7000 |
Produce process:
Packaging & Shipping
Packages:
packing in wooden box or by sheet
