Specifications of FRP Skylight Board with Aluminum Edge :
1. High Quality FRP plate
2. UV Protection
3. High strength, good light transmission
Technical date of FRP Plate
| Density | 1.45 g/cm3 | Tensile strength | 75Mpa |
| Fiber content | 25% - 35% | Bending strength | 125Mpa |
| Curing degree | >82% | Impact ductility | 90 KJ/M2 |
| Weathering film thickness | 20-30μm | Thermal conductivity | 0.158 W/m.k |
| Light transmissivity | 3% - 85% | Thermal expansivity | 2.6x10-5mm/mm/°C |
| Suitable temperature | -40~ +120 | UV Resistance | 100% |
Thickness of PRP plate:1.2mm ~ 1.8mm, tolerance ± 10%;
Thickness of coated steel tile: 0.5mm, the color should be consistent with the roof color plate;
Thickness of aluminum zine plate: 0.5mm
Weidth: <1.1m, different width according to the profile
Length: According to the demand
Color: Clear blue, Light blue, Lake blue, Sky blue, Deep blue, Clear white, Solid white, Gray white, Black, Clear green or Customizable
Product Types: Single layer skylight, insulation double layers skylight in normal
Features: Anti condensation, heat insulation, noise insulation, good water tightness, ensure the roof structure, energy saving and environmental protection, 360 degree upright occlusion, good appearance.
Match the coated steel tile, easy installation. According to different customer needs to produce products that satisfy you!
Occlusion Types:
1. Single 360 degree of occlusion;
2. Double 360 degree of occlusion;
3. Single 180 degree of occlusion;
4. Double 180 degree of occlusion.
Advantages:
1. Vertical occlusion, avoid leakage and seepage;
2. Convenient installation;
3. Ensure the whole roof structure
4. Low cost maintenance;
5. Prevent condensation
6. Good sound insulation, heat insulation, thermal preserve
Application : High demand electronics factory, valuables storage workshop, high precision machine shop, cold regions need to heat insulation lighting workshop, etc.
1. How many profiles you have? We want to make the profile with our design, whether you can make it?
------- We have various profiles you can choice at present, also Sennuo Company can provide the OEM service.
2. How do you pack?
------- Sennuo Company pack the goods with wood in normal, the wood can do the fumigation. Also we can pack the goods according to our client’s require.
3. How many colors you have? Whether you can make the color according to our sample?
------- 10 colors you can choice, also Sennuo can make the color as our client’s require.
4. How many types you have? We want to make the different type, whether you can make it?
--------There are single layer and double layers in normal. Also you can tailor make: high temperature resistant type, anti-corrosion type, Grade I fire retardant type, Grade II fire retardant type, flame retardant anti-weathering type and anti weather resistant transparent type.
5. What’s your delivery day?
------- 15 days in normal.
6. We need to make the sample, whether it is free?
------- The client need to pay the sample cost at first, when they order a full container goods, we will return the sample cost to them. So, it mean that the sample cost is free.
