UAS EURO HOT SALE UNDERFLOOR HEATING CABLE
Product Features:
1. Construction:
Outer Sheath: Poly Vinyl Chloride (PVC)
Grounding line: Tinned copper wire
Shielding layer: aluminum
Conductor: Alloy resistance
Insulation: XLPE
Connector: internal
2. Dimensions:
outer diameter: 6.5mm
3. Parameter:
Power Supply Voltage: 220V (can be customized/custom-made)
Linear power: 18W/m
4. More:
length of cold wire: 2.5m
Max work temperature: 70°C
20170215
Flat Heating Cable list:
Specification Power(W/r) Length(m/r) Resistance(Ω/r)
OGILLT-1R-300/18 | 300 | 16.7 | 161.3 |
OGILLT-1R-500/18 | 500 | 27.8 | 96.8 |
OGILLT-1R-800/18 | 800 | 44.4 | 60.5 |
OGILLT-1R-1000/18 | 1000 | 55.6 | 48.4 |
OGILLT-1R-1200/18 | 1200 | 66.7 | 40.3 |
OGILLT-1R-1400/18 | 1400 | 77.8 | 34.6 |
OGILLT-1R-1600/18 | 1600 | 88.9 | 30.3 |
OGILLT-1R-1800/18 | 1800 | 100.0 | 26.9 |
OGILLT-1R-2000/18 | 2000 | 111.1 | 24.2 |
OGILLT-1R-2200/18 | 2200 | 122.2 | 22.0 |
OGILLT-1R-2400/18 | 2400 | 133.3 | 20.2 |
OGILLT-1R-2600/18 | 2600 | 144.4 | 18.6 |
OGILLT-1R-2800/18 | 2800 | 155.6 | 17.3 |
OGILLT-1R-3000/18 | 3000 | 166.7 | 16.1 |
This is Kien from Qunxing, Please contact us for more specifications!
