16mm2 pvc wire
- 1 Kilometer / Kilometers per Month
- Shenzhen Shanghai Ningbo
- T/T L/C D/P D/A Credit Card PayPal
- Mooring rope cable
- Manufacturer of waterproof gas electric composite cable for air ducts, specialized cable for underwater divers
- The difference between different types of automotive cables and selection advice
- China manufacturer Communicate cable RVVP 4*0.3mm2 for power generation
- IEC62196-2 mode 3 16A single-phase electric vehicle charging process
- Automotive high-voltage cables with protection class IP67 characteristics
Product Details
Place of Origin: | Guangxi, China | Brand Name: | Qunxing | Model Number: | BV,BLV |
Insulation Material: | PVC | Type: | Low Voltage | Application: | Construction |
Conductor Material: | Copper | Jacket: | PVC |
Product Description
Specifications
16mm2 pvc wire1.Conductor: ALuminum,Copper
2.Insulation: PVC
3.U0/U: 450/750V
4.CCC certification
16mm2 pvc wire
1.Specification
1) Rate voltage U0/U: 450/750V,300V/500V,300V/300V.
2) Temperature Range:70-90°C
3) Conductor: Copper or Aluminum
4) Insulation: PVC
5) Colours:Black,Brown,Red,Orange,Yellow,Green,Blue,Purple,Gray,White,Transparent,Yellow/green etc
2. Characteristic
High/low temperature resistant, anti-acid, anti-oil, antisepsis and moisture
3. Application
Apply to Household appliance, Illumination and Lighting and Headlamp, electric machines, temperature sensor Military series, Metallurgy Chemical series, Motor cars and Ships Electrical Installation.
Model | Name |
BV | Copper Core PVC Insulation Wire |
BLV | Aluminum Core PVC Insulation Wire |
BVR | Copper Core PVC Insulation Flexible Wire |
BVV | Copper Core PVC Insulation PVC Sheath Round Wire |
BVVB | Copper Core PVC Insulation PVC Sheath Flat Wire |
BLVVB | Aluminum Core PVC Insulation PVC Sheath Flat Wire |
BV-90 | Copper Core Heat-resistance 105oC PVC Insulation |
Specification Size and Technical Data
Nominal | Conductor | Nominal | Max overall | Condcutor | Min insulated | Weight | ||
sectional area | No/Dia. | Insulated thick | Dia. | Resistance at | resistance at | Kg/km | ||
mm2 | mm | mm | mm | 20 | 70MΩ/km | |||
Cu | Al | Cu | Al | |||||
1.5 | 1/1.38 | 0.7 | 3.3 | 12.1 | - | 0.011 | 19.2 | - |
1.5 | 7/0.52 | 0.7 | 3.5 | 12.1 | - | 0.01 | 20.6 | - |
2.5 | 1/1.78 | 0.8 | 3.9 | 7.41 | 11.8 | 0.01 | 30.8 | 15 |
4 | 1/2.25 | 0.8 | 4.4 | 4.61 | 7.39 | 0.0085 | 45.5 | 21 |
6 | 1/2.76 | 0.8 | 4.9 | 3.08 | 4.91 | 0.007 | 65 | 29 |
10 | 7/1.35 | 1 | 7 | 1.83 | 3.08 | 0.0065 | 110 | 52 |
16 | 7/1.70 | 1 | 8 | 1.15 | 1.91 | 0.005 | 170 | 70 |
25 | 7/2.14 | 1.2 | 10 | 0.727 | 1.2 | 0.005 | 270 | 110 |
35 | 7/2.52 | 1.2 | 11.5 | 0.524 | 0.868 | 0.004 | 364 | 150 |
50 | 19/1.78 | 1.4 | 13 | 0.387 | 0.641 | 0.0045 | 500 | 200 |
70 | 19/2.14 | 1.4 | 15 | 0.268 | 0.443 | 0.0035 | 688 | 269 |
95 | 19/2.52 | 1.6 | 17.5 | 0.193 | 0.32 | 0.0035 | 953 | 360 |
120 | 37/2.03 | 1.6 | 19 | 0.153 | 0.253 | 0.0032 | 1168 | 449 |
150 | 37/2.25 | 1.8 | 21 | 0.124 | 0.206 | 0.0032 | 1466 | 551 |
185 | 37/2.52 | 2 | 32.5 | 0.099 | 0.164 | 0.0032 | 1808 | 668 |
Flexible wire
Nominal | Conductor | Nominal | Max overall | Condcutor | Min insulated | Weight |
sectional area | No/Dia. | Insulated thick | Dia. | Resistance at | resistance at | Kg/km |
mm2 | mm | mm | mm | 20 | 70MΩ/km | |
2.5 | 9/0.41 | 0.8 | 4.2 | 7.41 | 0.011 | 33 |
4 | 19/0.52 | 0.8 | 4.8 | 4.61 | 0.009 | 48 |
6 | 19/0.64 | 0.8 | 5.6 | 3.08 | 0.0084 | 68 |
10 | 49/0.52 | 1 | 7.6 | 1.83 | 0.0072 | 115 |
16 | 49/0.64 | 1 | 8.8 | 1.15 | 0.0062 | 176 |
25 | 98/0.58 | 1.2 | 11 | 0.727 | 0.0058 | 272 |
35 | 133/0.58 | 1.2 | 12.5 | 0.524 | 0.0052 | 384 |
50 | 133/0.68 | 1.4 | 16.5 | 0.387 | 0.0051 | 510 |
70 | 189/0.68 | 1.4 | 16.5 | 0.268 | 0.0045 | 714 |
95 | 259/0.68 | 1 | 19.5 | 0.139 | 0.0035 | 965 |
120 | 259/0.76 | 1.8 | 22 | 0.153 | 0.0032 | 1210 |
150 | 259/0.85 | 1.8 | 25 | 0.124 | 0.0032 | 1510 |
