lw price manufacturers 5 ton wheel loader625 Earth-moving Machinery
- 100 Set / Sets per Month
- any port in China
- T/T Credit Card
Product Details
Condition: | New | Brand Name: | SDSW | Model Number: | SDSW 652B |
Type: | Front Loader | Moving Type: | Wheel Loader | Dimension(Long * Breadth * High): | 7960*3068*3380, 7960*3068*3380(mm) |
Rated Load: | 5 tons | Certification: | ISO9001,CE | Warranty: | 1 year |
Product Description
lw price manufacturers 5 ton wheel loader625 Earth-moving Machinery
loader characters
country Ⅱ emission engine,low speed,low speed and big torque optimization design,more save power,more high efficient,more reliable
17 MPa high pressure design,caterpillar WuXi factory produce's DIN standard high pressure pipe,more reliable
optimize the whole machine arrangement,improve the whole loader's stability
brake caliper add prevent proof,prelong the service life of brake disc,improve the brake system stability friction plate
adopts 2 pumps confluence,turn priority,load sensing hydraulic steering hydraulic system,the whole machine more flexible,light,work has better efficient.
transmission system optimization design,main clutch adopts high function ,improve the transmission system reliability,work efficient and fuel consumer economic
short wheelbase design,the whoe machine more suits narrow place work,work more efficient.
optimize work device,improve the lift ability
electric system optimized and upgrading,adopts high stage water-poof and dust-proof plug-in security system more reliability.
the whole machine design can reach country noise and security demand
technical data
model | SDSW652B |
bucket capacity | 2.7-4.5m ³ |
rated weight | 5 tons |
the whole machine operate weight | 16 tons |
max traction | 160KN |
max dig up force | 150KN |
max climb ability | 28 ° |
min bending radius (outside of bucket) | 7017mm |
min bending radius(outside of tire) | 6031mm |
bucket lift,titling,falling 3 item total | 10.8s |
unload height | 3156mm |
unload distace | 1222mm |
the wheelbase | 3000mm |
dimension | 7960*3068*3380 |
engine | |
model | steyr D10.21AT21 country Ⅱemission |
form | inline,vertical,water-cooled,4 stroke |
rated power | 154KW |
max torque | 920Nm |
transmission system | |
torque model | YJ375 |
form | single stage 3 components the centripetal type |
transmission type | fixed axis constant mesh type power shift |
gear | front 4 after 2 |
max loader speed | 42.2km/hour |
front and end drive axle | 4 wheel drive,front axle fixed,and end axle swing ±11 ° |
turn system | |
form | articulate frame,load turn,turn priority |
steering angle(left and right) | 35 ° ±1 |
work hydraulic system | |
work hydraulic system pressure | 17MPa |
operate method | mechanical |
brake system | |
travel brake | single pipe,gas cap oil four-wheel caliper disc brake |
brake and emergency brake | barely able to mainpulate and increase the within the hoof type |
tire | |
specification | 23.5-25 |
fuel capacity | |
fuel tank capacity | 266L |
hydraulic system capacity | 150L |
can choose device | |
WeiChai WD10G210E22 country Ⅱemission | |
U type load coal bucket and extended arm | |
extended arm | |
desert type tire | |
quick change and tools |
360 ° show the loader
bucket capacity
bucket add up,improve the produce efficient 12%,optimization the work device,improve the lift abilit
engine
country Ⅱ emission engine,slow speed of revolution,low speed and big torque optimization design,more environment protection,higher efficient,more save power
front and after bridge
box structure front and after frame,higher strength,and easy to maintenance.
front and after bridge
box structure front and after frame,higher strength,and easy to maintenance.
Our Services
1.We provide reasonable and practical design according to customers' request.
2.We send engineers to assemble and test the machine within the period as agreed in the contract.
3.Within warranty period, we provide free repair if quality problems emerge.
4.We supply high quality accessories in low price.Our company can provide you and loader brand,such as caterpillar,cat, komatsu,volvo, yanmar,doosan ....and we also can provide china own produce loader,we keep the quality,price from high to low,we all have.
why choose us?
1 High quality,our factory has many years experiences in this industry,and our loaders quality is the best in same industry.Compare with other country's loader,our loader more pritical,longer use life,design more humanized.And we provide you the easy damaged parts
2 factory price,you know because we are factory,companre with other comapnies,we are the direclty supplier.You can get the direcly price from us,save many process in the middle,so choose us,you will save lots of money.
3 Easy to maintenance: the whole machine is designed with simple structure. all the mechanical parts are connected strongly and easy to change by the operators. And we can provide you 1 set free standby use wearing parts
