Specifications
gsm smart alarm with ios android apps user manual, easy to use.the wireless advanced alarm system with lots of useful function
King Pigeon is a leading GSM Alarms, 3G Video Camera, GSM Alarm Systems, GSM SMS Controller Alarm, GSM Medical Alarm, GSM Telemetry, GPRS Data Logger Manufacturer from 2005 in the worldwide.
Products Line:
GSM Home Alarm Systems; 3G Video Camera Alarm;
GSM SMS Controller Alarms; GSM GPRS data Logger;
GSM Telemetry Systems (M2M); GSM Gate Opener.
The GSM SMS Security Alarm S120 is a User-Friendly concept and new security protection solution special for Residential areas, business area, commercial area, office, factory, industrial area and other Varity applications. The GSM SMS Security Alarm inbuilt one reliable quad-band GSM Module, integrated high performance MCU inside, includes lots of safety protection required functions, and lots of potential demands for safety protection applications, and integrated the User-Friendly Human-Machine Interface design and easy-to-use concepts. The GSM SMS Security Alarm S120 is very suitable to remotely monitoring assets from theft-against, safety condition detection, switch on or off electric equipments by simple SMS Commands from worldwide, no distance limitation.
Standard Package list of the GSM SMS Security Alarm
Control Unit X1
Regulated 12VDC Power Supply X1
Remote Keys X 2
Wireless Door Contact X1
Key X 2
GSM Alarm User Manual + Android Apps in CD X1
GSM Antenna X1
Specifications of Mainframe of the GSM SMS Security Alarm
Rated Voltage: 12VDC 2A
Standby current: 30-40mA
Siren Output Voltage: 12VDC
Working temperature: -10°C~+60°C
Storage temperature: -20°C~+60°C
Relative humidity: 10-90%, No condensation
GSM frequency: 850/900/1800/1900MHz
Communication protocol: GSM PHASE 2/2+ (include data service)
Wireless Zone: 16 (Accept Max.16Pcs Learning Code Detectors, Unlimited of fixed code Detectors)
Wired Zones: 20, Dry Contact, NC, NO,EOL.
Remote key permission quantity: 5Pcs
Effective distance wireless of remote control: 100 m in open air.
Backup Battery: 3 X 1200mAH Rechargeable lithium battery
Standby time Approx.18hours (depending on the network condition)
Dimensions: 225mmX160mmX50mm (WXDXH);
Net Weight: approx. 1.00Kg
Reference Standards:
The GSM SMS Security Alarm S120 reference lots of international standards.There are:
UL1023:2004: Safety Household Burglar-Alarm System Units
UL 985:2004: Household Fire Warning System Units.
UL1635: Digital Alarm Communicator System Units.
EN 55022:1998: Emission Standard for information Technology Equipment.
EN 50024:1998: Immunity Standard for Information Technology Equipment.
EN 50130-4:1996: Immunity Standard for Fire, Intruder and Social Alarm Systems.
EN 60950:2000: Safety of information technology equipment.
EN 50131-1: 2004: Intrusion Systems General Requirements-Security Grade 2, Environment Class II.
PD 6662:2004: Scheme for the application of European Standards for intruder alarm systems.
DD 243:2004: Installation and configuration of intruder alarm systems designed to generate confirmed alarm conditions-code of practice.
EN 300220: Electromagnetic Compatibility and Radio Spectrum Matters (ERM); Short Range Devices (SRD); Radio equipment to be used in the 25 MHz to 1 000 MHz frequency range with power levels ranging up to 500 Mw.
ETS 300683: Radio equipment and systems (RES) – Electromagnetic compatibility (EMC) standard for Short Range Devices (SRD) operating on frequencies between 9 kHz and 25 GHz.
EN 50136-2-1: Alarm systems. Alarm transmission systems and equipment. General requirements for alarm transmission equipment.
TBR 21: European Telecommunications Standards Institute.
