Computer Detector Wired Water/Oil Level Sensor WL-04

Computer Detector Wired Water/Oil Level Sensor WL-04 photo-1
Computer Detector Wired Water/Oil Level Sensor WL-04 photo-2
Computer Detector Wired Water/Oil Level Sensor WL-04 photo-3
Computer Detector Wired Water/Oil Level Sensor WL-04 photo-4
Computer Detector Wired Water/Oil Level Sensor WL-04 photo-5
Computer Detector Wired Water/Oil Level Sensor WL-04 photo-6
US$ 1 - 5 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
King Pigeon
Model Number:
WL-04
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name King Pigeon
Model Number WL-04
Usage Other, water

Computer detector Wired water/Oil level sensor WL-04



water level sensorThe water level sensor is an input to monitor the water level, when the water level in the tank higher than or lower than the related float ball, the sensor will trigger.
Apply to water level alarm and control systems, e.g.: tank level monitoring, oil tank level monitoring and river level monitoring and so on.
 Computer detector Wired water/Oil level sensor WL-04
It can work with our GSM alarm systems.
 Computer detector Wired water/Oil level sensor WL-04
The specification of the water level sensor is in the table. (we will not supply the other size sample, but we can supply the other size according to the customers special requirements.)

Model
WL-04

Mainbody Material
Steel Material 304
Floating ball Material
PP
Contact
Dry Contact,  OKI30-35 10W or HAMLIN25-30
Connection wire
UL1007   24AWG
Work Temperature
-20°C~80°C
Application
Water (If use for oil, the floating ball material should be NBR material)
Wiring Specification
White Color wire: Low Level
Bule Color wire: Middle Level
Red Color Wire: High Level
Black Color Wire: Com
Normal Type
NC
Package
1.00KG
