Name:  Distributed Data Acquisition Modules 8-Channel Pt Resistance Thermometer Module

Model:DAM304



The DAM304 is for measuring 8-channel Pt resistance thermometer of PT100, PT500, PT1000, CU50,CU100 or other PT Resistance Thermometers and transmit in ASCII data format to any RTU, SCADA, data monitoring, data loggers, PLC’s, process controllers and instrumentation that supports Modbus RTU Protocol over RS485 serial port. Powered up by 10~30VDC.

The DAM304 is used widely in industrial automation temperature measurement systems. E.g.: Base Transceiver Station, diesel generator rooms, engine room, transformer substations, telecommunication equipment rooms, power supply systems and so on.

The DAM304 is an industrial class, isolated designed, high reliability, low-power consumption, high stability and high precision data acquisition module.

The DAM304 with fire retardant shell, standard 35mm DIN rail makes it easy to install in fields.

Distributed Data Acquisition Modules 8-Channel Pt Resistance Thermometer Module model

Mainly Features:

  • 24-bit resolution high precision AD acquisition and data processing techniques;
  • Wide range power supply with reverse polarity connection protection;
  • Modbus RTU Protocol;
  • ESD Protection circuit for RS485 serial port;
  • Using industrial-grade chips;
  • Built-in watchdog ensure it reliability;
  • Lightning protection ensure it stability;
  • LEDs for status indication makes it easy to program in filed.



Specifications:

Items

Specifications

Rated Power Input

10~30VDC(Peak Voltage must≤40V)

Power Consumption

Typically ≤0.5W

Communication Protocol

Modbus RTU

Modbus Address

1~247

Data Format

n,8,1; e,8,1; o,8,1 or n,8,2

Communication Interface

RS485

Baud Rate

1200, 2400, 4800, 9600, 19200, 38400Bps

Measurement Channel

8

Pt Resistance Thermometer

Default:PT100; Optional:PT500,PT1000,CU50,CU100 and other PT Resistance Thermometers

Thermometer Wires

Default: 2 Wires; Optional: 3 Wires.

Measurement Precision

±0.1%FS

Isolated Type

Input / power / RS485 Serial port isolated

Withstand Tests

Input /Output /Shell: 2000VAC/min.; 500VDC>100 MΩ

Installation Type

35mm DIN Rail

Operation Temperature

-20~70°C;

Storage Temperature

-40~85°C;

Relative Humidity

5~95%RH.;(at -40°C, non condensate)

Altitude

0~3000m

Temperature Drift

≤100ppm/°C

Dimension

118×72×59mm mm(HxWxD)

Net Weight

105g.
