Data Acquisition Module Rs485 Modbus Gsm Energy Meter Remote Transmitter King Pigeon DAM124 SeriesUS$ 1 - 10MOQ: 1 Piece
-
Data Acquisition Unit, Data Collection Device,data Logger Part Modbus RS485US$ 1 - 10MOQ: 5 Pieces
Name: 4DIN+8AI+4DO Module Model:
MODEL: DAM134
4DIN+8AI+4DO Module Model 4DIN+8AI+4DO Module Model 4DIN+8AI+4DO Module Model4DIN+8AI+4DO Module Model
The DAM134 is for monitoring 8 analog inputs, measuring 4-channel Pt resistance thermometer of PT100, PT500, PT1000, CU50,CU100 or other PT Resistance Thermometers and transmit in ASCII data format to any RTU, SCADA, data monitoring, data loggers, PLC’s, process controllers and instrumentation that supports Modbus RTU Protocol over RS485 serial port. Powered up by 10~30VDC.
The DAM134 is for monitoring 8 analog inputs, measuring 4-channel Pt resistance thermometer of PT100, PT500, PT1000, CU50,CU100 or other PT Resistance Thermometers and transmit in ASCII data format to any RTU, SCADA, data monitoring, data loggers, PLC’s, process controllers and instrumentation that supports Modbus RTU Protocol over RS485 serial port. Powered up by 10~30VDC.
The DAM134 is used widely in industrial automation control systems. E.g.: Base Transceiver Station, diesel generator rooms, engine room, transformer substations, telecommunication equipment rooms, power supply systems and so on.
4DIN+8AI+4DO Module Model 4DIN+8AI+4DO Module Model 4DIN+8AI+4DO Module Model4DIN+8AI+4DO Module Model
The DAM134 is an industrial class, high reliability, low-power consumption, high stability and high precision data acquisition module.
4DIN+8AI+4DO Module Model 4DIN+8AI+4DO Module Model 4DIN+8AI+4DO Module Model4DIN+8AI+4DO Module Model
The DAM134 with fire retardant shell, standard 35mm DIN rail makes it easy to install in fields.
Mainly Features:
1. 24-bit resolution high precision AD acquisition and data processing techniques;
2. 8 analog input, can be 0~20mA,4~20mA,0~5V,0~10V;
3. Wide range power supply with reverse polarity connection protection;
4. Modbus RTU Protocol;
5. ESD Protection circuit for RS485 serial port;
6.Using industrial-grade chips;
7. Built-in watchdog ensure it reliability;
8. Lightning protection ensure it stability;
8. LEDs for status indication makes it easy to program in filed.
Specifications
Items |
Specifications |
Rated Power Input |
10~30VDC(Peak Voltage must≤40V) |
Power Consumption |
Typically ≤0.3W |
Communication Protocol |
Modbus RTU |
Modbus Address |
1~247 |
Data Format |
n,8,1; e,8,1; o,8,1 or n,8,2 |
Communication Interface |
RS485 |
Baud Rate |
1200, 2400, 4800, 9600, 19200, 38400Bps |
Analog Input |
Default: 4~20mA, optional: 0~20mA, 0~5V, 0~10V |
Update Period |
0.12~2.4S |
Measurement Channel |
8AIN+4Pt |
Pt Resistance Thermometer |
Default:PT100; Optional:PT500,PT1000,CU50,CU100 and other PT Resistance Thermometers |
Thermometer Wires |
Default: 2 Wires; Optional: 3 Wires. |
Measurement Precision |
±0.2%FS |
Input Resistance |
Analog channel: Voltage:>1KΩ, current ≤150Ω |
Overload Capacity |
1.2 times can sustained,3 times voltage can last 1 second. |
Isolated Type |
Input / power / RS485 Serial port isolated. |
Withstand Tests |
Input /Output /Shell: 2000VAC/min.; 500VDC>100 MΩ |
Installation Type |
35mm DIN Rail |
Operation Temperature |
-20~70℃; |
Storage Temperature |
-40~85℃; |
Relative Humidity |
5~95%RH.;(at -40℃, non condensate) |
Altitude |
0~3000m |
Temperature Drift |
≤100ppm/℃ |
Dimension |
118×72×59mm mm(HxWxD) |
Net Weight |
160g. |
