Body Parameters: | ||
Dimension |
3160×1720×1230mm |
|
Wheel Base |
935×1070mm |
|
Track |
1420mm |
|
Minimum Ground Clearance |
260mm |
|
Curb Weight |
750kg |
|
Rated Load |
On Land:500kg(6 People) On Water:300kg(4 People) |
|
Performance Parameters: | ||
Start Mode |
Key |
|
Ignition Mode |
EFI |
|
Battery Specification |
12V/60Ah |
|
Drive Mode |
On Land: All-wheel Drive On Water: All-wheel Drive or Outboard Drive |
|
Top Speed |
On Land: 60km/h On Water: 5km/h(Tyre Stroke)or 12km/h(15HP Outboard) |
|
Minimum Turning Radiu |
0.71m |
|
Maximum Climbing Angle |
32 º |
|
Approach Angle |
64 º |
|
Departure Angle |
78 º |
|
Brake Mode |
Caliper Hydraulic Brake |
|
Tyre Specification |
28×12-12NHS |
|
Tyre Pressure |
14psi (96.5kPa) |
|
Transmission Mode |
Belt and Chain Transmission |
|
Dynamic Parameters: | ||
Engine Model |
SQR472 |
|
Engine Type |
Vertical 4-Cylinder, Water-cooling, 4-Stroke, Inline DOHC |
|
Oil-supply Mode |
MPI |
|
Cylinder Diameter ×Stroke |
4-72×66.5mm |
|
Displacement |
1083ml |
|
Compression Ratio |
9.5:1 |
|
Rated Power and Turning Speed |
50kW(6000r/min) |
|
Max. Torque and Turning Speed |
90N·m(3500~4000r/min) |
|
Idle Speed |
850±50r/min |
|
Lubricating Mode |
Pressure and Splash Lubrication |
|
Cooling Mode |
Forced Circulation and Antifreeze Coolant |
|
Clutch System |
CVT |
|
Transmission Type |
CVT+2 Forward Gears, Neutral, Reverse Gear |
|
Fuel Type |
Gasoline 93# |
|
Oil Tank Capacity |
38L |
|
Others: | ||
Optional Equipment: Adjustable Seat (Front ), Bumper, winch, Drain Equipment, Traction Ball Head and seat, Rear Foot Pedal, Winch, Foldable Windshield, Windshield Wiper, Top, Anti-roll Rack, Alert Lamp, Heating System, Outboard Motor Breakwater Board, Snow Plough, Air cushion, Utility Storage Pouch, Vehicle Cover, Fire-fighting Equipment, etc. | ||
Performance Characteristics: 6×6 All Wheel Drive, Braking Differential Steering, CVT, 32 Degree Climbing, 360 Degree Turning on the Ground, 1.2 Meter Wide Trenches Across, ±40 ℃ Temperature Work and Full-sealed High Strength Vehicle Body etc. | ||
Functionality: Rescue, Exploration, Hunting, Fishing, Tourism, Entertainment etc. | ||
Application Scope: All Terrains such as Swamp, Beach, Non-paved Road; Rivers, Lakes and other Calm Waters ( 4 grade water); Hills, Snow Land, Forest, Desert etc. | ||
