ATV

NO.

Item

Descripton

1

Dimension (L×W×H)

1530mm×900mm×1020mm

2

Proper Mass of Empty Vehicle

130kg

3

Max speed

>=55km/h

4

Grad ability

>=15°

5

Distance between axles

1030mm

6

Distance between front wheels

735mm

7

Distance between rear wheels

670mm

8

Ground clearance

120mm

9

Specification of Front Wheel

20*7-8, 50Kpa

10

Specification of Rear Wheel

19*9.5-8,   50Kpa

11

Type of Engine

P157QMJ

12

Bore x Stroke

57.4mm*57.8mm

13

Efficient Capacity

124.6ml

14

Rated Power and Rotate Speed

5.9KW/7000r/min

15

Max Torgue and Rotate Speed

8.3N.m/6000r/min

16

Compressing Ratio

9.0:1

17

Gearshifts Mode

stepless

18

Starting System

Electric and kick-back starting

19

Cooling System

Air cooled

20

Fuel tank capacity

4.5L

21

Packing size

1450* 820 * 840 mm

22

Gross weight

141 KG
