Specifications
road wrecker:1.rated towing weight:7.3T
2.Maxlifting weight:1.5T
3.Maxlifting weight of full extension:8T
KFM5190TQZ08S-SQZ8040slv III KaiFan Middle-duty S Series (HOWO) Road Wrecker
Working Condition:
1.Altitude: 0-4500m
2.Temperature: -35°C--+45°C
3.Relative humidity: 80%
4.Wind force: ≤8degree
Working Range :
KFM5190TQZ08S Road wrecker is used for safety salvage of vehicles subject to city road, suburb way, highway, airport and bridge road. It is suitable for medium and small-sized cargos, cars and other special vehicles, which are allowed within the technical parameters of this kind.
Main Parameters:
Boom Structure | Rated lifting weight | kg | 5745 |
Max. Lifting weight of original place | kg | 8000 | |
Max. Lifting weight of full extension boom | kg | 4000 | |
Rated towing weight | kg | 19000 | |
Max. Towing weight | kg | 40000 | |
Effective length of boom | m | 3560 | |
Extension traveling of boom | m | 1700 | |
Folding angle of boom | ° | 90 | |
Under lift Structure | Max. Rated hanging weight | kg | 8000 |
The height from hook to the ground | mm | 5690 | |
Max. Extension traveling of lifting boom | mm | 2800 | |
Rotation angle | ° | 34 | |
Rated pulling power of winch | kg | 2×6000 | |
Length of steel cable | m | 40 | |
Min. Speed of steel cable | m/min | 7 | |
Vehicle Parameters | External dimension | mm | 8929×2500×3210 |
Chassis model |
| ZZ1167N5618W | |
Axle base | mm | 5600 | |
Drive |
| 4×2 | |
The whole weight of empty load | kg | 13125 | |
Load of front axle of empty load | kg | 6000 | |
Load of rear axle of empty load | kg | 7125 | |
The whole weight of full load | kg | 19000 | |
Load of front axle of full load | kg | 6000 | |
Load of rear axle of full load | kg | 13000 | |
Wheel base (front/rear axle) | mm | 2022/1830 | |
Front suspension | mm | 1500 | |
Rear suspension | mm | 1109 | |
Approach angle | º | 14 | |
Departure angle | º | 18 | |
Min. Ground clearance | mm | 260 | |
Min. Turning diameter | m | ≤19.5 | |
Max. Speed | km/h | 90 | |
Max. Grade ability | % | ≥30 | |
Engine model | - | WD615.95 | |
Engine emission | L | 9.726 | |
Power/Speed | kw/r/min | 247/2200 | |
Max. Torque/Speed | n·m/r/min | 1350/1100~1600 | |
Fuel type |
| Diesel | |
Standard of emission |
| EN III | |
Tire size |
| 12.00-20 | |
Persons |
| 2 | |
Optional Engine | Engine model |
| P11C-UH |
Rated power | kw | 240 | |
Engine emission | ml | 10520 | |
Engine model |
| WD615.96 | |
Rated power | kw | 276 | |
Engine emission | ml | 9726 | |
Engine model |
| WD615.95C | |
Rated power | kw | 249 | |
Engine emission | ml | 9726 | |
Engine model |
| WD615.96C | |
Rated power | kw | 279 | |
Engine emission | ml | 9726 |
