Light-duty Recovery Truck,Road wrecker
Working Condition:
1.Altitude: 0-4500m
2.Temperature: -35°C--+45°C
3.Relative humidity: 80%
4.Wind force: ≤8degree
Working Range :
KFM5074TQZ Road wrecker is used for safety salvage of vehicles subject to city road, suburb way, highway, airport and bridge road. It is suitable for medium and small-sized cargos, cars and other special vehicles, which are allowed within the technical parameters of this kind.
Main Parameters
Items | Unit | Value | |
Boom Structure | Rated towing weight | kg | 7200 |
Rated lifting weight | kg | 3000 | |
Max. Lifting weight of full extension boom | kg | 1500 | |
Effective length of boom | mm | 1800 | |
Extension traveling of boom | mm | 650 | |
Folding angle of boom | ° | 98 | |
Under lift Structure | Rated hanging weight | kg | 1500 |
The height from hook to the ground | mm | 3500 | |
Numbers of winch | piece | 1 | |
Max. Pulling power of winch | kg | 4000 | |
Diameter of steel cable | mm | 10 | |
Length of steel cable | m | 25 | |
Min. Speed of steel cable | m/min | 4.5 | |
Rotation angle | ° | 32 | |
Vehicle Parameters | External dimension | mm | 5830×1980×2425 |
Chassis model |
| NKR77PLPACJAY | |
Axle base | mm | 3815 | |
Drive |
| 4×2 | |
The whole weight of empty load | kg | 4075 | |
Load of front axle of empty load | kg | 2000 | |
Load of rear axle of empty load | kg | 2075 | |
The whole weight of full load | kg | 7205 | |
Load of front axle of full load | kg | 2500 | |
Load of rear axle of full load | kg | 4705 | |
Wheel base (front/rear axle) | mm | 1504/1425 | |
Front suspension | mm | 1015 | |
Rear suspension | mm | 790 | |
Approach angle | º | 24 | |
Departure angle | º | 26 | |
Min. Turning diameter | m | ≤15.2 | |
Max. Speed | km/h | 100 | |
Grade ability | % | 30 | |
Min. Ground clearance | mm | 190 | |
Engine model | - | 4KH1-TC | |
Rated power | kw/r/min | 96/3400 | |
Max. Torque | n·m/r/min | 280/1700 | |
Engine emission | L | 2.999 | |
Fuel type |
| Diesel | |
Standard of emission |
| EN III | |
Tire size |
| 7.00-16(option7.50-15,7.50R15,7.00R16) | |
Persons |
| 2 | |
