KFM5074TQZ-SQZ1507N-QA KaiFan Light-duty N Series (ISUZU) Recovery Truck

FOB Price

USD $29,999 - $34,999 / Set

1 Set(Min.Order)

Supply Ability 200 Set / Sets per Month
Port Dalian Port
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Fuel Type	Diesel	Emission Standard	Euro 3
Condition	New	Transmission Type	Manual
Dimensions (L x W x H) (mm)	5830x1980x2425mm	Place of Origin	Liaoning, China
Brand Name	Kai Fan	Model Number	KFM5074TQZ-SQZ1507N-QA

Product Description

Specifications

recovery truck
1.rated towing weight:7.3T
2.Maxlifting weight:1.5T
3.Maxlifting weight of full extending boom:8T

KFM5074TQZ-SQZ1507N-QA KaiFan Light-duty N Series (ISUZU) Recovery Truck

Working Condition:

1.Altitude: 0-4500m

2.Temperature: -35°C--+45°C

3.Relative humidity: 80%

4.Wind force: ≤8degree

Working Range :

KFM5074TQZ Road wrecker is used for safety salvage of vehicles subject to city road, suburb way, highway, airport and bridge road. It is suitable for medium and small-sized cargos, cars and other special vehicles, which are allowed within the technical parameters of this kind.

Main Parameters

Items		Unit	Value
Boom Structure	Rated towing weight	kg	7200
	Rated lifting weight	kg	3000
	Max. Lifting weight of full extension boom	kg	1500
	Effective length of boom	mm	1800
	Extension traveling of boom	mm	650
	Folding angle of boom	°	98
Under lift Structure	Rated hanging weight	kg	1500
	The height from hook to the ground	mm	3500
	Numbers of winch	piece	1
	Max. Pulling power of winch	kg	4000
	Diameter of steel cable	mm	10
	Length of steel cable	m	25
	Min. Speed of steel cable	m/min	4.5
	Rotation angle	°	32
Vehicle Parameters	External dimension	mm	5830×1980×2425
	Chassis model		NKR77PLPACJAY
	Axle base	mm	3815
	Drive		4×2
	The whole weight of empty load	kg	4075
	Load of front axle of empty load	kg	2000
	Load of rear axle of empty load	kg	2075
	The whole weight of full load	kg	7205
	Load of front axle of full load	kg	2500
	Load of rear axle of full load	kg	4705
	Wheel base (front/rear axle)	mm	1504/1425
	Front suspension	mm	1015
	Rear suspension	mm	790
	Approach angle	º	24
	Departure angle	º	26
	Min. Turning diameter	m	≤15.2
	Max. Speed	km/h	100
	Grade ability	%	30
	Min. Ground clearance	mm	190
	Engine model	-	4KH1-TC
	Rated power	kw/r/min	96/3400
	Max. Torque	n·m/r/min	280/1700
	Engine emission	L	2.999
	Fuel type		Diesel
	Standard of emission		EN III
	Tire size		7.00-16(option7.50-15,7.50R15,7.00R16)
	Persons		2
