SHITONG 40T/H Portable Continuous Asphalt Concrete Mixer

Name: SHITONG 40T/H Portable Continuous Asphalt Concrete Mixer
Brand: SHITONG
SKU: 141683088
Availability: InStock

Jinan Shanglong International Trade Co., Ltd.

US$ 44,000 - 49,000 MOQ: 1 Unit

Key Specifications

Condition:

New

Place of Origin:

Shandong, China

Brand Name:

SHITONG

Payment & Shipping

Payment Methods:

Port of Shipment:

China Port

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Shandong, China

Brand Name SHITONG

Model Number GLB40

Motor Power 32KW

Mixing Power 32KW

Charging Capacity 60T/H

Reclaiming capacity 30T/H

Specifications

Asphalt Concrete Mixer
1) Type: Portable, Continuous, Modular
2) Outputting: 40 t/h
3) Drying roller
4) Power: 32 kw

Asphalt Concrete Mixer

SHITONG 40T/H Portable Continuous Asphalt Concrete Mixer

1) Pictures

2) Specifications

Technical Specification
MAIN PARAMETER
Model	GLB30/40
Type	Modular, Easy to Assemble and Disassemble, Movable and Continuous.
Outputting	30~40 t/h
Power	32 kw
COLD AGGREGATE HOPPER
Type	With separate net set at the storage’s door
Capacity of set as flat	4 m³
Capacity of set as pile	5.5 m³
Quantity	3 units
AGGREGATE CONVEYER BELT
Type	Channel frame support with three points
Outputting	60 t/h
Belt width	500 mm
Geared motor	BWD13—17—1.5kw
FEEDING BELT
Type	Channel frame support with three points
Outputting	60 t/h
Belt width	500 mm
DRYING ROLLER
Type	Tilt roller which has rotary and counter-current fluent
Productivity	40 T/H in the station of moisture content is 3% and outputting material temperature is 150°C
Roller specification	φ1200mm×4800mm
Geared Motor	BWY27—29—7.5kw
Drive type	By gear
COAL MILL
Type	Used on the coal burning plant
Model	FD—65
Power	11 kw
BLOWER
Model	Y4—72—5A
Power	2.2kw—2P
OIL BURNER
Oil pump	1.1 kw
Blower	15 kw
ASPHALT SUPPLYING SYSTEM
Asphalt pumps	50 asphalt pumps with 4kw
DUST REDUCING DEVICE
Type	Clean the dust by wind which induced at the end
Draft fan	15 kw
OTHER
Finished material storage	1 m³
Control Cabinet	One
