400cc ATV 4WD Automatic Clutch EEC ATV (TKA400E-B)

400cc ATV 4WD Automatic Clutch EEC ATV (TKA400E-B) thumbnail-1
400cc ATV 4WD Automatic Clutch EEC ATV (TKA400E-B) photo-1
US$ 2,000 - 3,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Fuel:
Gas / Diesel
Displacement:
>300cc, >400cc
Engine Type:
4 Stroke, 4 Stroke
Contact Supplier Request Quote Chat Now
Ningbo Tuokai Sports Vehicle Co., Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Fuel Gas / Diesel
Transmission Type Other, Semi-Automatic, Automatic
Transmission System Shaft Drive
Certification Other, ECE, EEC
Brand Name TUOKAI
Model Number TKA400E-B

Specifications

400CC ATV,400cc automatic clutch eec atv, 400cc eec epa atv, china atv, eec atv, quad atv

 400cc ATV 4WD Automatic clutch EEC ATV (TKA400E-B)400cc ATV 4WD Automatic clutch EEC ATV (TKA400E-B)400cc ATV 4WD Automatic clutch EEC ATV (TKA400E-B)

400CC ATV,400cc automatic Clutch eec atv, 400cc eec epa atv, china atv, eec atv, quad atv

Dimension(L×W×H): 2100×1210×1200mm
Wheelbase: 1320mm
Distance between front wheels: 920mm
Distance between rear wheels: 935mm
Ground clearance: 280mm
Seat height: 920mm
Dry weight: 312kgs
Gross weight: 368kgs
Fuel tank: 13L
Max speed: 85km/h
Brake system (front/rear): Disk/Disk
Gearshift mode: Automatic clutch,five speeds,one neutral with inside reverse gear
Transmission mode: Shaft
Drive system: 4WD/2WD
Steering angle: 36°
Tire front: 25×8-1224×8-12
Tire rear: 25×10-1224×9-11
Cargo front: 331bs(15kg)
Cargo rear: 881bs(40kg)
Suspension: F/R Double suspension
Tow weight limit: 3376N(385kgf/8501bs)
Tongue weight: 137N(14kgf/30bs)
Engine
Engine model: 179F
Efficient Capacity: 359.1ml
Engine type: 4-stroke,Single-Cylinder
Cooling system: Air-cooled + Oil-cooled
Rated power and rotate speed: 13.5kw(5500r/min)
Max torque and rotate speed: 24N.m(4000r/min)
Compression ration: 8.8:1
Bore×stroke: 78.5*74.2mm
Carburetion
Oil Capacity: 2L
Economical oil consumption(L/100km): ≤7
Electrical
Battery: 12V-14Ah
Starting system: Electric/Hand-pull
Ignition:  DCDI
Quantity: 8 units/20; 18 units/40; 27 units/40HQ (WITHOUT REAR BOX)
8 units/20; 18 units/40; 27 units/40HQ (WITH REAR BOX)
Packing Size 2320x1270x850 mm
