4wheels ATV 500cc (TKA500E-A)

4wheels ATV 500cc (TKA500E-A) thumbnail-1
4wheels ATV 500cc (TKA500E-A) thumbnail-2
4wheels ATV 500cc (TKA500E-A) thumbnail-3
4wheels ATV 500cc (TKA500E-A) thumbnail-4
4wheels ATV 500cc (TKA500E-A) thumbnail-5
4wheels ATV 500cc (TKA500E-A) thumbnail-6
4wheels ATV 500cc (TKA500E-A) photo-1
4wheels ATV 500cc (TKA500E-A) photo-2
4wheels ATV 500cc (TKA500E-A) photo-3
4wheels ATV 500cc (TKA500E-A) photo-4
4wheels ATV 500cc (TKA500E-A) photo-5
4wheels ATV 500cc (TKA500E-A) photo-6
US$ 2,700 - 3,300 MOQ: 1 Unit
Key Specifications
Get Latest Price
Fuel:
Gas / Diesel
Displacement:
>300cc, 500cc
Engine Type:
4 Stroke, 4 Stroke
Contact Supplier Request Quote Chat Now
Ningbo Tuokai Sports Vehicle Co., Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Fuel Gas / Diesel
Transmission Type Other, Automatic, Automatic
Transmission System Shaft Drive
Certification Other, ECE, EEC/EPA
Brand Name TUOKAI
Place of Origin Zhejiang, China
Model Number TKA500E-A

500cc Shaft drive 4x4 Quad

CTV, 4WD ATV with EEC&COC Certificate



alloy rims/camo color/winch/towball/snow plough etc optional.

2015 newest options: windshield

 4wheels ATV 500cc (TKA500E-A)4wheels ATV 500cc (TKA500E-A)

=============================================================================================

Specification
Engine type 500cc,water cooled,4-stroke,single-cylinder,4-valve
Bore*Stroke 92mm*75mm
Compression ratio 10.2:1
Carburetion single chamber
Lubrication Pressure splash
Ignition CDI
Starting system electric
Transmission Belt CVT fully auto with H,L,N,R manual gear shifting
Front brake system front/dual hydraulic disc,twin pistons
Rear brake system rear/hydraulic disc,self-adjust parking system,shaft mounted
Drive train 2WD/4WD adjustable by push button,rear wheels always lock,no differential,shaft drive
Suspension 4-wheels independent suspension
Tires size front/AT25*8-12 rear/AT25*10-12
Dimension 2050*1150*1450mm
wheelbase 1280mm
Turning radius 3600mm
Ground clearance 230mm
Fuel capacity 10.5L
Dry weight 340kgs
Front bed capacity 20kgs
Rear bed capacity 40kgs
Towing capacity 500kgs
Total capacity 260kgs
Max Power 24 kw / 6800r / min
Max Torge 38 N.m / 5000r /min
Max speed 85KM/H
Container loading 20'ft/10pcs
Accessories winch,trainer coupling,alloy rims



optional longer version EEC approved for 2seats

2015 newest options:  Widened fender trim panel

4wheels ATV 500cc (TKA500E-A)

basic EEC approved for sinlge seat

4wheels ATV 500cc (TKA500E-A)4wheels ATV 500cc (TKA500E-A)4wheels ATV 500cc (TKA500E-A)4wheels ATV 500cc (TKA500E-A)4wheels ATV 500cc (TKA500E-A)
