2/4WD 400cc EEC&EPA Quad ATV (TKA400E-B)

2/4WD 400cc EEC&EPA Quad ATV (TKA400E-B) thumbnail-1
2/4WD 400cc EEC&EPA Quad ATV (TKA400E-B) photo-1
US$ 2,900 - 3,500 MOQ: 1 Unit
Key Specifications
Get Latest Price
Fuel:
Gas / Diesel
Displacement:
>300cc, 400cc
Engine Type:
4 Stroke, 4 Stroke
Contact Supplier Request Quote Chat Now
Ningbo Tuokai Sports Vehicle Co., Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Fuel Gas / Diesel
Transmission Type Other, Semi-Automatic, simi-Automatic cluth
Transmission System Shaft Drive
Certification Other, EEC&EPA, EEC/EPA
Brand Name TUOKAI
Model Number TKA400E-B

Specifications

2x4/4x4 drive,
front and rear bumpers,
Electric shift,
alloy wheel,
Tail ball,head light, Independent suspension



400cc ATV 2WD/4WD simi-Automatic clutch,electric shift gear EEC ATV



ENGINE
Engine type 4-stroke,Single-Cylinder, Air/Oil-cooled
Displacement 359.1cc
Max power 13.6kW/5500r/min
Max torque 24N.m/4000r/min
Valve Configuration SOHC
Compression ratio 8.8:1
FUEL SYSTEM
Fuel Delivery System Carburetor
Choke System Manual Choke
Fuel capacity 13L(3.4Gallon)
DRIVETRAIN
Driveline Type 2X4
Final Drive shaft,front limited slip differential
Transmission Simi-Automatic clutch
Gear Selection Five speed, Neutral,Reverse, Park
ELECTRICAL SYSTEM
Forward Lights Headlights-High & Low Beam
Rear Lights Brake Lights & Left/Right Signal lights
Starting system Electric/Hand-pull
Ignition system DCDI
SUSPENSION / BRAKES
Suspension Front/Rear Independent double wishbone
Brakes Front/Rear Disk
TIRES
Front Tread 920mm(36.2in)
Rear Tread 935mm(36.8in)
Front & Rear tire size 25×8-12 / 25×10-12
MISC
Top speed 85km/h(53MPH)
Dry weight 312kgs(687.2lbs))
Shipping weight 358kgs(788lbs.)
Ground clearance 280mm(11in)
Fuel consumption 5.5L/100km
Wheelbase 1320mm(52in))
Vehicle dimension (L×W×H) 2100×1210×1200mm(82.7×47.6×47.2in)
Packing size 2300×1260×820mm(90.6x49.6x32.3in)
Loading information  8 units/20″; 18 units/40″; 27 units/40HQ



2/4WD 400cc EEC&EPA Quad ATV (TKA400E-B)2/4WD 400cc EEC&EPA Quad ATV (TKA400E-B)

2/4WD 400cc EEC&EPA Quad ATV (TKA400E-B)
