JLA-24-15 Atv Quad Japanese Quad Bike

JLA-24-15 Atv Quad Japanese Quad Bike thumbnail-1
JLA-24-15 Atv Quad Japanese Quad Bike thumbnail-2
JLA-24-15 Atv Quad Japanese Quad Bike photo-1
JLA-24-15 Atv Quad Japanese Quad Bike photo-2
US$ 1,340 - 1,780 MOQ: 2 Pieces
Key Specifications
Get Latest Price
Fuel:
Gas / Diesel
Displacement:
250cc
Engine Type:
4 Stroke
Contact Supplier Request Quote Chat Now
Yongkang Jinling Vehicle Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Fuel Gas / Diesel
Displacement 250cc
Engine Type 4 Stroke
Transmission Type Manual
Transmission System Chain Drive
Certification ECE
Brand Name JINLING
Place of Origin Zhejiang, China
Model Number JLA-24-15 japanese quad bike

 JLA-24-15 atv quad japanese quad bike-





Product Description

 JLA-24-15 atv quad japanese quad bike

 JLA-24-15 atv quad japanese quad bike



--------------------------------------------------------------------------------------------------------------------------------

BRAND NEW 2015 250CC ATV  250CC-V4D

JAPANESE QUAD BIKE

EEC AND CE APPROVED

JUST IN WITH BIGGER TIRE  and 10'' WHEELS

 BIGGER ,WIDER ,BETTER AND MORE POWER

QUALITY ENGINE BUILD, HYDRAULIC DISC BRAKE

FRONT SUSPENSION A-ARM,REAR SWING ARM

ADJUSTABLE AIR SHOCK FRONT,REAR

IDENTIFICATION
1.Model No. JLA-24-15-10-250DW JLA-24-15-10-250-F JLA-24-15-10-250AW
2.Warranty one year for engine, 6months for other parts
3.Model No. in EEC  certifcate
ENGINE
4.Cylinder Single Single Single
5.Cooled System water air water
6.Engine Stroke 4 Stroke 4 Stroke   4 Stroke
7.Bore*Stroke(mm) 72x61.2mm 71x58
8.Displacement(ml) 250cc 250CC 250CC
9.Max.power(kw/rpm) 12kw/7500rpm 13kw/7500rpm 10kw/7500rpm
10.Max.torque(n.m/rpm) 19.5N.m/3500rpm 17N.m/5500rpm 13.5N.m/5500rpm
11.Ignition Type CDI CDI CDI
TRANSMISSION
12.Transmission Type 4 fowarder gear,1 reverse gear semi-automatic CVT
13.Primary Drive(Rear Wheel) chain/shaft,drive shaft,drive chain/shaft,drive
14.Reverse Yes Yes Yes
15.Max Speed(km/h) 75 75 75
WHEEL
16.Front  wheel 23X7-10 23X7-10 23X7-10
17.Rear  wheel 22X10-10 22X10-10 22X10-10
SUSPENSION
18.Front Suspension  A x swing arm,  A x swing arm,  A x swing arm,
19.Rear Suspension mono shock swing arm mono shock swing arm mono shock swing arm
BRAKE SYSTEM
20.Front brake Drum Drum Drum
21.Rear brake Disc Disc Disc
22.Braking distance 8m(30km/h) 8m(30km/h) 8m(30km/h)
TECHINCAL SPECIFICATIONS
23.Product Dimensions(mm) 1890x 1180 x 1220mm 1890x 1180 x 1220mm 1890x 1180 x 1220mm
24.Ground Clearance(mm) 155 155 155
25.Wheelbase(mm) 1110 1110 1110
26.Mini Turning Radius(mm)
27..gross weight(kg) 228 228 229
28. net weight(kgs) 206 206 207
29.Fuel Capacity(L) 4 4 9.5
30.Fuel consumption     4.5L/100KM
SEAT
31.Seat Height(mm) 900 900 900
32.Number of Seats 2 2 2
COLOR
33.Standard Color Red/Yellow/Blue/Green/Black/White
34.Optional Color Green camo,Yellow camo,Snow Camo,Metallic,Carbon
LOADING
35.Packing Size(mm) 1940x1090x840mm
36.Quantity 20GP:12pcs      40HQ:36pcs
PRICE
37.MOQ 1X20FT 1X20FT 1X20FT
