150CC QUAD ATV BIKE JLA-13-10

150CC QUAD ATV BIKE JLA-13-10 thumbnail-1
150CC QUAD ATV BIKE JLA-13-10 thumbnail-2
150CC QUAD ATV BIKE JLA-13-10 thumbnail-3
150CC QUAD ATV BIKE JLA-13-10 thumbnail-4
150CC QUAD ATV BIKE JLA-13-10 thumbnail-5
150CC QUAD ATV BIKE JLA-13-10 thumbnail-6
150CC QUAD ATV BIKE JLA-13-10 photo-1
150CC QUAD ATV BIKE JLA-13-10 photo-2
150CC QUAD ATV BIKE JLA-13-10 photo-3
150CC QUAD ATV BIKE JLA-13-10 photo-4
150CC QUAD ATV BIKE JLA-13-10 photo-5
150CC QUAD ATV BIKE JLA-13-10 photo-6
US$ 540 - 850 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Fuel:
Gas / Diesel
Displacement:
150cc
Engine Type:
4 Stroke
Contact Supplier Request Quote Chat Now
Yongkang Jinling Vehicle Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Fuel Gas / Diesel
Displacement 150cc
Engine Type 4 Stroke
Transmission Type Automatic
Transmission System Chain Drive
Certification ECE
Brand Name JINLING
Place of Origin Zhejiang, China
Model Number JLA-13-10

 150CC QUAD ATV BIKE JLA-13-10-





Product Description





 150CC QUAD ATV BIKE JLA-13-10

150CC QUAD ATV BIKE JLA-13-10

--------------------------------------------------------------------------------------------------------------------------------

Quad ATV 150CC QUAD ATV BIKE JLA-13-10
150cc/200cc 4 stroke air cooled  Engine,
Chain drive,Automatic clutch,Drum/Disc
CE 8,10 inch road  wheel,Wide front A-ARM

CE

----------------------------------------------------------------------------------------------------------------------------------

Features:

This  Quad ATV 150CC QUAD ATV BIKE JLA-13-10 is jinling JLA-13-10 150CC/200CC, 4x2.  Jinling's are wonderful ATVs.

They are adult sized ATVs . These ATVs have a super reliable 4 stroke, air cooled engine with electric start and reverse(operation).

The transmission is a 1+1 speed handle shift unit so while you do have to shift with your foot you do not have to use a clutch.

----------------------------------------------------------------------------------------------------------------------------------

Specification:

 Quad ATV 150CC QUAD ATV BIKE JLA-13-10 JINLING JLA-13-10





IDENTIFICATION
1.Model No. JLA-13-10-10-150 JLA-13-10-10-200 JLA-13-10-10-200Y
2.Warranty one year for engine, 6months for other parts
3.Model No. in EEC  certifcate
ENGINE
4.Cylinder Single Single Single
5.Cooled System Air air oil
6.Engine Stroke 4 Stroke 4 Stroke 4 Stroke
7.Bore*Stroke(mm) 57.4×57.8mm 61x64.7mm 61x64.7mm
8.Displacement(ml) 149.6(150cc) 200CC 200CC
9.Max.power(kw/rpm) 7.0kw/7500rpm 7.5kw/6500rpm 7.5kw/6500rpm
10.Max.torque(n.m/rpm) 8.3N.m/5000rpm 10.5N.m/5000rpm 10.5N.m/5000rpm
11.Ignition Type CDI CDI CDI
TRANSMISSION
12.Transmission Type Automatic Automatic Automatic
13.Primary Drive(Rear Wheel) Chain    4x2 Chain    4x2 Chain    4x2
14.Reverse No Yes Yes
15.Max Speed(km/h) 60 70 70
WHEEL  click here
16.Front  wheel 21x7-10 21x7-10 21x7-10
17.Rear  wheel 20x7-10 20x7-10 20x7-10
SUSPENSION
18.Front Suspension Double  A-Swing Arm Double  A-Swing Arm Double  A-Swing Arm
19.Rear Suspension Swing Arm Swing Arm Swing Arm
BRAKE SYSTEM
20.Front brake Drum Drum Drum
21.Rear brake Disc Disc Disc
22.Braking distance 8m(30km/h) 8m(30km/h) 8m(30km/h)
TECHINCAL SPECIFICATIONS
23.Product Dimensions(mm) 1550x880x950 mm 1550x880x950 mm 1550x880x950 mm
24.Ground Clearance(mm) 100 100 100
25.Wheelbase(mm) 1000 1000 1000
26.Mini Turning Radius(mm) 2800mm 2800mm 2800mm
27..gross weight(kg) 173 173 173
28. net weight(kgs) 158 158 158
29.Fuel Capacity(L) 4.5 L 4.5 L 4.5 L
30.Fuel consumption 3.8L/100KM 4.0L/100KM 4.0L/100KM
SEAT
31.Seat Height(mm) 750 750 750
32.Number of Seats 1 1 1
COLOR
33.Standard Color Red/Yellow/Blue/Green/Black/White
34.Optional Color Green camo,Yellow camo,Snow Camo,Metallic,Carbon
LOADING
35.Packing Size(mm) 1490x840x750    (Steel frame inside,carton outside)
36.Quantity 20FT:33PCS,   40HQ:66PCS 20FT:33PCS,   40HQ:66PCS 20FT:33PCS,   40HQ:63PCS
PRICE
37.MOQ 1X20FT 1X20FT 1X20FT
