High Quality and Cheap Tricycle 2 Speed Rear Axle With Mechanical Brake

High Quality and Cheap Tricycle 2 Speed Rear Axle With Mechanical Brake thumbnail-1
High Quality and Cheap Tricycle 2 Speed Rear Axle With Mechanical Brake thumbnail-2
High Quality and Cheap Tricycle 2 Speed Rear Axle With Mechanical Brake thumbnail-3
High Quality and Cheap Tricycle 2 Speed Rear Axle With Mechanical Brake thumbnail-4
High Quality and Cheap Tricycle 2 Speed Rear Axle With Mechanical Brake photo-1
High Quality and Cheap Tricycle 2 Speed Rear Axle With Mechanical Brake photo-2
High Quality and Cheap Tricycle 2 Speed Rear Axle With Mechanical Brake photo-3
High Quality and Cheap Tricycle 2 Speed Rear Axle With Mechanical Brake photo-4
US$ 110 - 200 MOQ: 1 Set
Key Specifications
Get Latest Price
Use For:
Cargo
Driving Type:
Motorized
Displacement:
> 250cc
Contact Supplier Request Quote Chat Now
Chongqing Xianyou Technology Development Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Use For Cargo
Driving Type Motorized
Body Type Open
Certification Other, ISO9001
Brand Name Xianyou
Place of Origin Chongqing, China
Model Number Full-Floating

Specifications

1.Factory directly manufacture and wholesale price
2.Customized by clients' requirements
3.Used for minicar, tricycle, UTV

PART ONE: ABOUT OUR PRODUCTS

    High quality and cheap tricycle 2 speed rear axle with mechanical brake

1.Different from other similar rear axles, because installed the same function synchronizer as the automobile one.

2.Therefore, it’s more reliable in driving with less bumping so that the life of the gear and box body is longer.

3.However, when the vehicle used, load should be warned.

High quality and cheap tricycle 2 speed rear axle with mechanical brakeHigh quality and cheap tricycle 2 speed rear axle with mechanical brakeHigh quality and cheap tricycle 2 speed rear axle with mechanical brake



Description

High quality and cheap tricycle 2 speed rear axle with mechanical brake

Structure

Semi-floating

Bearing

6206-RS/6007/6008

Brake

Mechanical brake or oil brake

Length of rear axle

700mm<L<1220mm

Ratio

10/28*24/29,10/28*17/36

Input spline

20*17*4

Material

60*4(GB/T8162-1999 seamless steel tube

Rim lock bolt

4-M12*1.25

Rear axle tube

60mm/65mm/70mm

Speed

2 speed

Delivery

Within 30days

Load capacity

<=1T

Wheel hub diameter

180mm, 200mm, 220mm

Net weight

50kg



Our Field (some pictures of rear axle)

High quality and cheap tricycle 2 speed rear axle with mechanical brakeHigh quality and cheap tricycle 2 speed rear axle with mechanical brakeHigh quality and cheap tricycle 2 speed rear axle with mechanical brake

PART TWO: ABOUT OUR COMPANY

Detailed information

Company NameChongqing Xianyou technology development co., Ltd.
Established Timefounded in 1998
Company CharacterWas specialized in pow machinery research, development
and manufacture high-tech Enterprise
Factory Producereverse gear, transmission, gearbox, gears and rear axle, used for the three wheeled motorcycle,
ATV, UTV, speedboat. We can produce rear axle for mini car
and electric vehicle
Awardin 2002-the gold medal of China quality “Wan Li Xing”
In 2009-obtained the national high and new technology enterprise
certificates issued by ministry of science and technology
In 2008-four product standards and Chongqing key new product and
excellent key new product certificate by chongqing two
diferent authority Official institutions
Patents18 national patents
Hardware FacilitiesWe have 2 assembly workshop, 2 machining workshop, a district- leve
l R&D center, 3 semi-automatic assembly lines, 60 sets of spiral
bevel gear milling machine, 20 sets of Case processing Machine, 8
sets automatic welding machine and 100 sets CNC machining equipment
Production capacityreverse gear annual output can reach 700,000 sets; rear
 axle can reach 81,000 sets; gear box can reach 827,000 sets.

High quality and cheap tricycle 2 speed rear axle with mechanical brake

High quality and cheap tricycle 2 speed rear axle with mechanical brake

High quality and cheap tricycle 2 speed rear axle with mechanical brake

1.Our Company and factory

High quality and cheap tricycle 2 speed rear axle with mechanical brake

2. Factory equipments

  High quality and cheap tricycle 2 speed rear axle with mechanical brake

High quality and cheap tricycle 2 speed rear axle with mechanical brake

High quality and cheap tricycle 2 speed rear axle with mechanical brake

3. Shipment

High quality and cheap tricycle 2 speed rear axle with mechanical brake

Service

1 Reply your inquiry in 24 working hours.

2 Experienced staffs answer all your questions in professional and fluent English.

3 Customized design is available and OEM&ODM are welcome.

4 Exclusive and unique solution can be provided to our customers by your well-trained and professional engineers staff.

5 Special discount and protection of sales are provided to your distributor.

Thanks



Mobile Phone:0086-023-15870495318

Fax:86-023-68967923

Skype:Tom Huang

QQ:651634884

Address:No. 6, Dongshan Road, Area B, Jiulong Park, Jiulongpo District, Chongqing, China

Zip:400000

Alibaba TradeManager:cn1510244529
