Specifications
1.Chinese cheap tricycle rear axle2.It has 2 speed ,high and low
3.Good quality and competive price
4.Best service
| Chinese cheap tricycle rear axle | |
| Structure | Full /semi floating |
| Bearing | 32009 tapered bearing |
| Brake | oil / mechnical brake |
| Length of rear axle | 700-1210mm(From hub to hub) |
| Ratio | 4.1 6.4 |
| Input spline | 20*17*4 |
| Material | 60*4(GB/T8162-1999 seamless steel tube) |
| Rim lock bolt | 5-M14*1.5 right-and-left threaded |
| Rear axle tube | 60mm |
| Speed | 2 speed |
| Wheel hub diameter | 220mm |
| PCD | 5*140 |
| Offset | 120mm |
| Delivery | Within 30days |
| Load capacity | < 2T |
| Net weight | 50kg |
| Fit engine | from 50cc--400cc |
Chinese cheap tricycle rear axle
1.Chinese cheap tricycle rear axle is different from other similar rear axles, because installed the same function synchronizer as the automobile one. 2.Therefore, it’s more reliable in driving with less bumping so that the life of the gear and box body is longer. However, when the vehicle used, load should be warned. |
Diiferent angle for rear axle
Advantages of this floating rear axle assembly
<1> the good bearing capacity
<2> easily installing
<3>reduce power consumption
<4> Flexible speed change and strong Traction power
other related rear axle assembly for your reference
<1>semi-floating 180mm diameter of <2> 2+1shafts full-floating rear axle assembly
rear axle assembly with Variable
speed
Advantage:1> High performance and reasonable Advantage 1> can realize reverse function and variable
price speed function together.
2> high bearing with simple installing 2> no need reverse device to install in tricycle
3>no need transimiision and change torque because the reverse function in rear axle
4> thick rear axle shell tube and good material 3> change gear flexible.
Packaging details
A. anti-rust paper, carton, and wooden case
B. custom packaging according to your specifications
our company
| Our Company Name | Chongqing Xianyou Technology Development Co., Led. |
| Established Time | founded in 1998 |
| Our Company Character | specialized in machinery research, development and manufacture , high-tech Enterprise |
| Our Factory Product | all kinds of gears, gear box, rear axle for tricycle |
| Our Award | in 2002-the gold medal of China quality “Wan Li Xing” |
| in 2009-obtained the national high and new technology enterprise | |
| certificates issued by ministry of science and technology | |
| in 2008-four product standards and Chongqing key new product and excellent key new product | |
| certificate by Chongqing two different authority Official institutions | |
| Patents | 18 national patents |
| Hardware Facilities | We have 2 assembly workshop, 2 machining workshop, a district- level R&D center, 3 semi-automatic assembly lines, 60 sets of spiral bevel gear milling machine, 20 sets of Case processing. Machine, 8 sets automatic welding machine and 100 sets CNC machining equipment |
| Production capacity | reverse gear annual output can reach 700,000 sets; rear axle can reach 81,000 sets; gear box can reach 827,000 sets. |
our office and factory
our workshop
our equipment
our certificate
