Home > Products > Special purpose truck > SINOTRUK HOWO Mobile lubrication truck
SINOTRUK HOWO Mobile lubrication truck
- 100 Unit / Units per Month
- China main port
- T/T L/C D/P D/A
- Top-Quality D9 Spray Truck: 147-169kW Power for Professional Road Cleaning Services
- Heavy-Duty 18-Ton D9 Spray Rig: Industrial-Grade for Unmatched Dust Suppression
- KLF5180GPSE6 D9 Sprayer: Premium Water-Cooled Engine for Reliable Performance
- 18-Ton D9 Spray Machine: Robust 13.8m³ Tank for Extensive Sanitation Needs
- Durable D9 Water-Cooled Spray Truck: Designed for Intensive Urban Cleaning Operations
- Powerful 18-Ton D9 Sprayer: Engineered for Large-Scale Road Maintenance
Product Details
Condition: | New | Transmission Type: | Manual | Emission Standard: | Euro 2 |
Fuel Type: | Diesel | Dimensions (L x W x H) (mm): | 8400X2496X3700 | Gross Vehicle Weight: | 16000 |
Place of Origin: | Shandong, China | Brand Name: | sinotruk howo | Model Number: | ZZ1167M4611 |
Product Description
Specifications
Certification:CCC ISO9001.Material:H1250 H850 Q345A
High quality and better price.
Engine
Make and model…………………..………….. WD615.62
Type………….. Diesel 4-stroke direct injection engine, 6-cylinder in-line with water cooling, turbo-charging & intercooling
Displacement................................................ 9.726 liters
Maximum output………………..…..266 HP@ 2200 rpm ( 196KW @ 2200 rpm )
Max. torque .......................... 1100NM@1300-1600 rpm
Bore ………………………………………………...126 mm
Stroke ………………………………………………130 mm
Mean piston speed ………………………………11.5 m/s
Compression ratio……….……………………………16:1
Specific fuel consumption …………..……...197 g/kWh
Engine oil filling quantity ……………………….19 liters
Cooling system filling quantity ……………….40 liters
Thermostat with 71℃ opening begin Rigid fan
Clutch
Model………...........................................................φ420
Type ..............Single dry plate, compressed air assistant
Plate diameter..........................……….............φ420mm
Gearbox
Type..….........................………..... FULLER 8JS100B
No. of speeds ................................ 8 forward, 1 reverse
Forward ratio................................ 11.4; 7.94; 5.63; 4.06; 2.81; 1.96; 1.39; 1.00
Reverse ratio... .........................….........................11.35
Front axle
Type.…….Rigid stub axle with double T-cross members
Max. load............................................................ 6500Kg
Tandem axle
Type..........……………….…………Pressed axle housing, single reduction with planetary wheel reduction
Ratio..............................................……...………….....4.8
Max. load.......................................................….13000Kg
Frame
Type................................ parallel ladder with U-profiles and riveted cross members
Steering
Type.....................................................................ZF8098
Ratio................................................................……..26.2
Fuel tank capacity…………………………..…..400L
Wheels and tires
Rim……..............................................…..............8.50-20
Tire ……..........……………….……Triangle 11.00-20 /16
Quantity………………………………………………….7
Brakes
Service brake.................Double circuit pneumatic brake
Parking brake.............. Spring-powered air-cut off brake
Assistant brake..................Engine exhaust brake
HOWO Cabin
All-steel forward control, 70° hydraulically tiltable to the front, 3-arm windscreen wiper system with 3 speeds, laminate windscreen, with casted-in radio aerial,
Electric equipment
Operating voltage ………...…..24 V, negative grounded
Starter…………………………………………24 V, 5.4 kW
Alternator……………………………………..28 V, 1500W
Battery voltage / capacitance……….……2x12V/165Ah
Cigar-lighter, horn, headlamp, fog light, reverse light
Front wheel alignment
Camber.…………………………….………………..........1º
Caster.....………………………….…………………........3º
King pin inclination...……………………………….......1º
Toe-in(measured at the wheel diameter φ648mm with cross-ply tyre) ....……………………..…...3-4.5mm
Overall dimension (length×width×height) .....………….………….....8400×2496×3700mm
Body dimension (length x width) …….…4500 x 2300 x2000mm
Wheelbase....………………….………......4600+1350mm
Track
Front.....…………………………….….……….....2022mm
Rear.......…………………………………………...1830mm
Approach angle...………………………………….......18º
Departure angle.......…………………………………...17º
Performance
Max. driving speed......………….……………....90 km/h
Turning circle diameter ..……………….….......... 16m
Mass parameter
Kerb mass.……………………………………........9070Kg
Total mass.........……...…………………………. 19000Kg
Diesel air compressor: 1 units
Model: WY-3/7-A
Flow: 3m3/min
Working pressure: 0.7Mpa
Rotating speed: 1000r/min
Cooling: air cooling
Diesel power: 25 Kw
Kerb mass: 1200kg
Grease pump: 6 units
Grease air pump
Modle: A75-G
Air input ressure: 4~9Kg/cm2
Barrel Capacity: 200L
Pressure ratio:45:1
Grease Output Pressure: 180~405Kg/cm2
Deliver Rate: 30cc/sec
Hose Length: 20 ft
N.W.:26.5kg
G.W.:28.5kg
Grease pipe: 10m with grease gun and automatic pipe winch
