shenghui hot sale automatic meat cutting machine cutter machine
company website:/
Product pictures
meat cutting machine
| type | QX-250 | QH-500 | QE-500 | QW-800 | QJ-1000 | QD-1500 |
| voltage | 220v/110v | 220v/110v | 220v/110v | 220v/380v | 220v/380v | 220v/380v |
| power | 0.55kw | 0.55kw | 0.55kw | 0.75kw | 0.75kw | 1.5kw |
| weight | 33kg | 35kg | 40kg | 70kg | 75kg | 110kg |
| size | 460*320*430 | 530*330*450 | 540*310*690 | 670*360*730 | 590*460*900 | 700*670*900 |
| cutting size | 2.5-50mm | 2.5-50mm | 2.5-50mm | 2.5-50mm | 3-50mm | 4-50mm |
| output | 250kg/h | 500kg/h | 500kg/h | 800kg/h | 1000kg/h | 1500kg/h |
At the bottom exist wheels, moving flexibly and using conveniently. Cutter is adopted external hanging design. Revolving speed of rotating part is changed for the second time by leather belt and motorcycle chain. Easy-to-use operation, convenient washing and dismounting, time and labour saving. If processing different thickness meat, just install the corresponding cutter. The cutter gap is customizable. Inside the machine exists safety switch. When cutter exposure outside, it locks automatically to ensure safety. Blades are made of special steel products, with hardness of 52, durable in use.
meat cutting machine
| type | QJT-250 | QJA-500 | QJB-800 |
| voltage | 220v/110v | 220v/380v | 220v/380v |
| power | 0.55kw*2 | 0.55kw*2 | 0.75kw*2 |
| weight | 66kg | 84kg | 145kg |
| size | 435*435*485mm | 540*500*870mm | 670*670*930mm |
| cutting size | 2.5-50mm | 2.5-50mm | 2.5-50mm |
| output | 250kg/h | 500kg/h | 800kg/h |
Two motors, working separately, cut meat into slices, working at the same time, cut meat into shreds, cut again, and come out diced meat. One machine serves several purposes. At the bottom of machine exist wheels, moving flexibly and using conveniently. Cutter is adopted external hanging design. Revolving speed of rotating part is changed for the second time by leather belt and motorcycle chain. Easy-to-use operation, convenient washing and dismounting, time and labour saving. If processing different thickness meat, just install the corresponding cutter. The cutter gap is customizable. Inside the machine exists safety switch. When cutter exposure outside, it locks automatically to ensure safety. Blades are made of special steel products, with hardness of 52, durable in use.
meat cutting machine
| type | QR-400JW | QR-400JL | QR-DQ1 | QR-SQ1 |
| voltage | 220v | 220v | 220v/380v | 220v/380v |
| power | 750w | 750w | 1.1kw/0.75kw | 1.1kw/0.75kw |
| weight | 43kg | 42kg | 55kg | 58kg |
| size | 610*310*575 | 345*310*575 | 380*280*700 | 350*280*700 |
| output | 400kg/h | 400kg/h | 300kg/h | 300kg/h |
Name: Economical Horizontal Meat Cutter Type: QR-400JW
Output: Slices: 300KG/H Shreds: 200KG/H Economical Horizontal Meat Cutter is with beautiful appearance, compact in structure, horizontal design. So the body is more pratical, sturdy and durable. The performance of this machine is stable, safe and reliable. Easy operation, convenient cleaning. This machine is specially cut for no bone meat, which is the first choice for catering industry, canteens nd food processing factory.
Name: Economically Vertical Meat Cutter Type: QR-400JL Output: Slices: 300KG/H Shreds: 200KG/H
Economically Vertical Meat Cutter with elegant appearance, compact structure, solid and durable. 220V and 380V motors can be selective, Stable performance, safe and reliable, convenient cleaning. Mainly cutting meat which with normal temperature , and no bone.
Name: Vertical Meat Cutter Type: QR-DQ1 Product Usage: Slices and shreds are available Sphere of Application: Meat Processing Equipment, frozen Meat Equipment, Canteen and Catering Industry.
QR-DQ1 vertical meat cutter is Easy-to-use operation, convenient washing and dismounting, time and labour saving. Mainly used to meat slices and shreds, and make different cutters according to customers’ requirement. If processing different thickness meat, just install the corresponding cutter. The cutter can not be adjustable.
Name: Vertical Meat Cutter (double cutting) Type: QR-SQ1 Product Usage: Slices and shreds are available
Sphere of Application: Meat Processing Equipment, frozen Meat Equipment, Canteen and Catering Industry. QR-DQ1 vertical meat cutter is Easy-to-use operation, convenient washing and dismounting, time and labour saving. the main feature is that have double feeding hole, Their specification are 3.5MM and 6MM separately. If processing different thickness meat, just install the corresponding cutter. The cutter can not be adjustive.
meat cutting machine
Name: Double Frequency Converter Cooked Meat Cutting Machine
Type: SH-125S-2
Voltage: 220V
Power: 1.125KW
Output: 200-500KG/H(depend on the thickness)
Weight: 80KG
Size: 1040×440×1280MM
Double Frequency Converter Cooked Meat Cutting Machine has a special design whose knife is made of hardening stainless steel as an arced shape. The knife’s speed can be controlled. In addition, it has a conveyor which can also has a speed regulation. It suits for cutting roast pork, stewed pig ears, braised skin of pig’s head, roast beef into pieces, slices and dices(the cutting thickness can be customized). This machine is easy handling and cleaning, meeting the requirements of food processing factory, fast food industry and canteen.
Details
Video introduction:
/watch?v=sV1wS9-V-_o&feature=youtu.be
FAQ
1. What is best method of cleaning and maintenance the tool ?
Answer: Wash with water, can also be appropriate to join detergent to clean it. Tool maintenance: after each tool is cleaned, it should to dry. And then you should coated it with cooking oil to keep the cutting tool lubrication and anti-oxidation.
2. What is the machine maintenance?
Answer:Maintenance methods: machine should be added lubricant on the chain, the gear, bearing every six months, reduction gearbox should add oil.If the machine frequently used, it is recommended that each quarter will be maintenance once a year. If the machine with a belt, conveyor belt, spring, every quarter to check whether is flabby, found relaxation timely adjustment or replacement.
3. If the cutter is blunt, or oxidation with a yellow, how to do?
Answer:If the cutter is blunt, you can grind the knife with grinding wheel or oilstone. If the cutter is oxidation with a yellow, you can use the scouring liquid to scrub, after washing you should add some cooking oil to protect the cutter.
4.How many hours a day the machine can continuously work?
Answer:Generally a machine can 24 hours of uninterrupted work. But we suggest that the machine should stop for a while after work 4-5hours. It has a certain protection on the machine.
5. How to choose and buy vegetable cutter, why the price has a big difference?
Answer: The vegetable cutter can be divided into melon cutting, vegetables cutting and fruitcutting. You can choose according to the material properties and yield. Some vegetable cutter price is high, there are magnetic control protection switch,.The cutting tool is easy to unpick and wash, the cutting effect is good, the blade material is good.
6. what are the advantages of ozone machine of vegetables cutter?
Answer:Ozone is known as a broad-spectrum, efficient, fast, safe, no secondary pollution of the gas sterilization. It can kill bacteria spores, viruses, fungi and can be damaged botulinum toxin. It can exterminate the escherichia coli, staphylococcus aureus, salmonella, aspergillus flavus,fusarium, penicillium, black variant of bacillus, natural bacteria, neisseria gonorrhoeae and so on which attached to the fruits, vegetables, meat and other food . It also can kill the infectious virus, such as hepatitis B and also can remove the pesticide residue in fruits and vegetables and washing product residue toxicity.
7Why choose shenghui's melon cleaning peeling machine?
Answer:( 1).Structure: Is open design, easy to clean up with slag filter or slag boxes(2) The motor and reducer is separation design, to reduce the machine resonance, prolong service life and reducing gear wear and tear.
(3)The both sides of the bearing is design by fully sealed , put an end to waste into the machine.(4) The material of brush is chosen high toughness bristles to reduce material loss(5)Circuit additional add to a overload protection device.(6)Lateral bearing retainer plate is thickening stainless steel plate, reducing machine vibration.(7)A discharging plate type is binding design, convenient one-handed operation.
Why choose us:
1. 10734 m*m factory area, 12 years experience
2. Warranty date :one year, MOQ: one piece
3. ISO, CE & FDA certificated
4. Fast delivery and good service
5. All of our products have been strictly inspected before shipment.
6. Customers first, satisfying customers forever
Transactions notes
Trade description:
We provide EXW of product in first quote in most cases, not containing shipping freight and taxes.
After-sales description:
1.Warranty of all product is one year, while consumable items, such as blades, knife tackles, motors and so on are beyond guarantee range
2.We own professional engineering department and maintenance department, providing perfect after-service for customers.
3.We're always in your service to deal with any problem occurs on machine you purchased from us.
4.Any product sold from our company is attached with a warranty card and a product instruction.
Logistics description:
Products delivered from our factory are required to be packed in standard wooden cases or cartons.
Maintenance:
1.After cleaning the cutters and accessories touching food, don't forget to dry liquid on surface before you re-assemble them on machine.
2.Lubricate the axis of cutter with edible oil. Dismantle the blunt cutter and polishing it by abrasive stick.
3.Add oil into the reducing gear-box every half a year; lubricate bearings, chains, gears inside machine with oil every quarter.
Attentions:
1.Place machine on the flat ground; trundles of wheeled machine should be locked if there is need to move it.
2.Make sure the feeding mouth equipped on machine should not be blocked by foreign objects,
3.Connect the ground wire and suitable power box based on required voltage described on the labels.
4.Keep hands away from the feeding mouth and outlet of machine when it is operating.
5.Cut power first to stop running machine before dismantling and cleaning the parts.
6.Be careful when dismantling and cleaning the cutter and other sharp part
7.Circuitry part is forbidden to clean.
