Automatic counting function wire coil winding machine for toroid transformer coil YW-260A
YW-260A wire coil winding machine for winding toroidal transformer is the new generation of winding equipment according to the power industry requirement and present manual winding technology of current transformer.
Main Technical Parameters Coil winding machine
Model | YW-260A/260AM | YW-300B/300BM | YW-400C/400CM | YW-500D/500DM |
Diameter range of windable electromagnetic wire | Φ0.5-1.5mm | Φ0.5-2.6mm | Φ0.5-3.2mm | Φ0.5-3.2mm |
Min inner diameter of winded coils | Φ 30mm | Φ 50mm | Φ 60mm | Φ 60mm |
Max outer diameter of winded coils | Φ 260mm | Φ 350mm | Φ 450mm | Φ 550mm |
Max height of winded coils | 70mm | 100mm | 140mm | 250mm |
Max winding rotation speed | 100rpm | 100rpm | 100rpm | 100rpm |
Machine tool power | 1.5KW | 1.5KW | 1.5KW | 1.5KW |
Max outline size of machine | 600*1000*1200mm | 700*1000*1300mm | 700*1000*1400mm | 850*1000*1500mm |
Remark: YW260AM/300BM/400CM/500DM mean that material is stainless steel.
Features
- PLC system,it has the machine tool wire storage automatic computation, automatic counting, automatic stop,stop memory and so on,and simplifies the operation greatly.
- Multi-wire winding mechanism,it realize the dual-wire or multi-wire multi-layer winding.
- High precision and wide application range.
- Low maintenance cost, energy saving and low noise.
- It can realize the continuous stepping stepless adjustment from 0.01mm.
- It is specially used for winding the circular coils of the small batch and many varieties.
Steps of Quality Control
- Strictly control the purchase standard of raw materials.
- With high precision equipments and rich experience workers to process components, make each process up to standard.
- Assembly process, recheck the quality of the components, the machine appearance etc.
- Before shipment, test all operating procedures by winding the core to ensure the machine work normally.
Test & Debug Automatic Toroidal Winding Machine
Packaging:
With plastic film and wooden case.
- The only manufacturer who can supply one-stop complete solution service for electric industry of resin products,we professional manufacture APG machine ,APG molds,casting molds,Toroidal winding machine,laser marking machine for whom produce CT,PT,insulators,contact box,etc,with best factory price and fast shipment.
- Professional rich experience engineers and research team, our engineers have more than 20 years experience who serviced many years in ABB, many patented products are owned by us.
- Have a line and lab special for producing CT and PT.we can winding samples and test in our lab.
- Professional Technique training, our engineer is available to train technique overseas or you send engineers learn technique from our factory.
- Full range of service.
- 24 hours service, email or call contact.
- Offer technology support before and after the sale.
- Provide high quality machines.
- Provide spare parts.
- Provide after-sales service.
