Home > Packaging & Printing > Packing Machinery > Sealing Machine > Automatic Single Line Lubricants Filling Machine
Automatic Single Line Lubricants Filling Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Beverage
Driven Type:
Pneumatic
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Automatic Single Line Perfume Filling MachineNegotiableMOQ: 1 Set -
Automatic Single Line Liquid Filling MachineNegotiableMOQ: 1 Set
-
Automatic Soybean Milk Stand-up Pouch Filler Screw CapperNegotiableMOQ: 1 Set
-
Single Nozzle Pneumatic Juice Filling MachineUS$ 1,000 - 2,500MOQ: 1 Set
-
Automatic Hoisin Sauce Filling and Capping MachineNegotiableMOQ: 1 Set
Condition
New
Application
Beverage
Driven Type
Pneumatic
Automatic Grade
Automatic
Power
1.5kw
Packaging Type
Bottles
Packaging Material
Other
Place of Origin
Shanghai, China
Brand Name
Leadworld
Model Number
LW-AFV4A
Specifications
1. Controlled by PLC, easy to adjust2. Use man-machine touch screen panel
3. Long service life
4. Low maintenance rate
- This machine is suitable for food medicine,chemistry,pesticide,lube and daily merchandise cosmetic etc.
- Auto Filler Line adopt pneumatic volumetric piston dosing filling principle,enter bottles,orientation,filling,transmitting bottles controlled by PLC,measured up to GMP,suitable for filling products at any kinds of material from aquiform to viscosity,suitable for food medicine,chemistry,pesticide,lube and daily merchandise cosmetic etc.
Adopts Piston pump with rotary valve
Filling nozzles with drip-proof
Conveyor with photo sensor
Machine cabinet
PLC and Human-computer touch screen. Etc
no bottle, no filling
This machine is customized, that means it can be 4 filling nozzles/ 6 filling nozzles/ 8 filling nozzles/ 12filling nozzles etc, according to the capacity customers need.
Using the rotating type pump and measuring the weight by Quantitative cylinder, filling quality is very accurate.
Features:
- Can setting filling time and specification.
- Turn into style filling ,prevent to bringing bubble availably.
- Control system use PLC,touching panel and man-machine interface provide many memory zones.
- Pivotal element use Eur-american or import element .
- No bottle stopped machine automatically ,easy to clean,easy to take apart and wash,you can dismantle and install without tool.
- This machine made of stainless steel and alnico,measure up to GMP.
- According to clients' bottles figure and filling require with our capping machine ,make particular design.
Technical Parameters:
|
Filling heads |
4, 6, 8 etc(based on the capacity) |
|
Filling volume |
0.5L, 1L, 1.5L etc(customized) |
|
Filling speed |
2000-3000(based on 6 nozzles) |
|
Filling precision |
≤±0.5% |
|
Power supply |
380V,220V 50-60HZ |
|
Power |
≤1.5kw |
|
Air pressure |
0.6-0.8MPa |
|
Net weight |
460kg |
|
Dimension(mm) |
1440*850*1600 |
