1. Hanzhong Burt Machinery Co., Ltd. is a comprehensive company which integrates services of design, manufacture, sales, installation, debugging, post-sales and accessory supply of grain dryer.
2. The company has independent import and export operation rights.
3. The level of product technology and quality are the leading position in the domestic.
4. The 5HXG series grain dryer adopts computer-controlled in the entire program.
5. There are two sets seed-special of drying program guaranteeing the food quality and seeds germination.
6. The high degree of automatization, simple operation, long working hours, high production efficiency.
7. The two core components, the fully automatic moisture tester and the high pressure spray burner, which are imported from Japanese and Italy respectively.
8. The 5HXG-10type grain dryer are certified by the Ministry of agriculture, and included the agricultural promotion directory.
9. Awarded the national patent technology, certified by ISO9001-2008.
10. In order to avoid the excessive drying adopts the automatic water testing stopping devices.
11. Drying various materials, such as rice, wheat, corn, rapeseed, cotton seed, soybean, sorghum, green beans, sunflower beans etc.
12. Work reliable, good durability, adaptability.
13. Installation and cleaning are convenient, safe and reliable in that the body is low.
14. Low-carbon, energy-saving.
15. Panel with the liquid crystal PLC control, which is easy to learn; you can directly reflect the dryer working status every time.
1. Spray burners is imported from Italy, automatically adjust fire by the control system which can ensure the
hot air humidity controlled in a certain range.
2. Eight-slot drying section, wide drying area, strong ventilation system, uniform drying.
3. Full computer touch screen control system
4. Burning the abandoned rice husk, firewood, straw, indirect heat extraction, clean hot air for drying material without any pollution.
Serial number |
Item |
Unit
|
Technical parameter |
|
1 |
Model |
/ |
5HXG-10, |
|
2 |
Type |
/ |
Batch circulation grain dryer |
|
3 |
Handling capacity(Moisture content of 22-24% of the maximum processing capacity) |
t |
Rice 10 |
|
4 |
Dimension (length×width×heighth) |
mm |
4100*1700*7510 |
|
5 |
Machine quality |
kg |
2500 |
|
6 |
Combustion engine |
/ |
Gun type spray |
|
7 |
Lighting mode of combustion engine |
/ |
Automatic lighting |
|
8 |
Fuel |
/ |
0#(diesel) |
|
9 |
Combustion consumption |
kg/h |
17.0-13.6kg/h |
|
10 |
Exhaust fan type |
/ |
Centrifugal
|
|
11 |
The air volume of exhaust fan |
m³/h |
10800 |
|
12 |
Automatic control and safety equipment |
/ |
Automatic moisture meter, temperature control, air pressure switch, motor overload protection automatic shutdown |
|
13 |
Matched power |
Grain discharge motor |
kw |
0.015 |
Fan motor |
4 |
|||
Dusting motor |
0.09 |
|||
On the auger motor |
1.5 |
|||
Under the auger motor |
0.75 |
|||
Circulation motor |
0.1 |
|||
14 |
Voltage |
v |
380 |
|
15 |
Drying capacity |
t%/h |
Rice 8-10 Wheat 7-10 |
|
If you want to know more information about our product, welcome to contact us in any time!
