Home > Transportation > Trailer > Truck Trailer > CLW 3 Axle Van Type Semi Trailer 50ton

CLW 3 Axle Van Type Semi Trailer 50ton

US$ 18,900 - 38,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Type:

Semi-Trailer

Material:

Steel

Certification:

Other, 3C

Contact Supplier Request Quote Chat Now

Chengli Special Automobile Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

any port in China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Type Semi-Trailer

Material Steel

Certification Other, 3C

Size 14600*2550*3980

OEM No. CLW9300X

Max Payload 50000

Place of Origin Hubei, China

Brand Name CLW

Model Number CLW9300X

CLW 3 axle Van Type Semi Trailer 50ton

Van Type Semi Trailer is also called Box Type semi trailer, it is the semi trailer type of Van Transport truck, it have all features of the Van Transport truck, but it can load more quality once . Of course, we also can customize kinds of Van type semi trailer according to the customer's request.

Production Introduction:

1 Factory direct sale
2 High quality, affordable price

3 Load 50 ton
4Three axle, opening top or closed top, double side opening doors

Main Parameter of CLW 3 axle Van Type Semi Trailer 50ton

Main Technical Parameter
Product Model	CLW Van Type Semi Trailer	*Overall Dimension(LWH)(mm)*	1460025503980
wheelbase(mm)	8160+1310+1310	*Inner Dimension (LWH)(mm)*	14400×2350,2460×2700
Curb weight(kg)	12200	Payload(kg)	50000
Rear tread(mm)	1840/1840/1840	Leaf Spring number:	-/8/8/8 or -10/10/10
Axle number	3	Rear axle load(Kg)	13000 or 16000
Tire size	11.00R20 12PR,11.00-20 12PR,12R22.5 12PR	Tire No:	12
Warranty	12 months, from the date of supply
Remarks	1. Used for transporting goods
	2. Box material: Corrugated iron, top is closed or opened, double sides opening doors
	3. 8 pieces twist locks, 28 ton outrigger, 90# king pin, ABS, FUWA or BPW axle, two tire carriers, one tool box

Multi-dimensional map of CLW 3 axle Van Type Semi Trailer 50ton :

Brief Introduction of Company:

ChengLi Special Automobile Co., Ltd ,which is appointed by the Ministry of Industry and Information Technology of China, is a big manufacturer producing all kinds of special trucks. It has registered trademark"CHENLIWEI" and the products code is CLW. It has solid technology,flawless inspection,advanced equipments,reliant quality and flexible modes of operation. What's more, it has roundly passed the certificaton of ISO 9001-2008 and the 3C Certification(China Compulsory Certification) and other certifications that export needed.

Since ChengLi company was established in Sep. 2004, ChengLi Special Trucks have always taken the top place in Chinese market in recent ten years and have procured remarkable achievements interiorly and oversea.

We can design and produce many kinds of special trucks accurately as your request. Our company own independent export right, and has a mount of clients overseas, such as the U.N., Sudan, Nigeria, North America, West Africa, Congo, Vietnam Ghana, Kazakhstan etc. We strives for the survival by the quality and credit standing is the guarantee of our success.

ChengLi Special Automobile co.,Ltd is located in Suizhou City, the native place of YanDi ShenNong,the hometown of BianZhong and the City of Special Truck. Welcome the friends from all over the world to SuiZhou! You will be the most enthusiastic reception.

Our certificates;

Production Equipments:

Contact Informtation:

If you have any questions, pls feel free to contact with me via e-mail or phone, I will try my best to help you. You can count on me. Please remember as below:
