Street sweeping truck is also called road sweeper, road sweeping truck, road sweeper truck, road sweeping vehicle, etc. There are two types of road sweepers we manufactured and they are broom sweepers truck, vacuum road sweeper truck. Following is the difference between our broom sweepers truck and vacuum road sweeper truck.
1.In the structure
The brushes sweeper truck is with 4 sets of brushes, water spraying device and suction disc. The suction sweeper trucks without brushes and water spraying device, it only with suction disc.
2.In the fuction
The brushes sweeper truck must open the water spraying device to restrain the dust before start sweep, but besides the dust, it can sweep the large garbage, almost the 1/3 brick.
The suction sweeper truck only can work at dry road to suck the dry dust. It mainly used to sweep the dusty street. It can suck the dust whose diameter almost 2.5 micrometres. But it can't sweep the larger garbage.
In the fact, you can choose the sweeper truck type according to the road station, with more garbage or with more dust.
3.About the price
The dust sweeper price is USD2000 higher than the brushes sweeper truck base on the same model.
The road sweeper trucks we maufacture has large sweep range, low fuel consumption, convenient operation
and other advantages. They are mainly used to sweep the road garbage of street, highway, dock, station,
square, cement mill, electric power plant,etc.
Pictures of 4x2 road sweeper truck
Dust suction disc pictures
Technical parameters of small dongfeng vacuum road sweeper truck
[Main Technical Parameters] | ||||
Product Name |
Sweeper Truck |
Product Model |
CLW5061TSL3 |
|
Gross Vehicle Weight(Kg) |
6495 |
Curb Weight(Kg) |
4865 |
|
Overall Dimension(mm) |
5970×2000×2380 |
Cab Allowed Persons |
3 |
|
Dive Type |
4x2 |
Wheelbase(mm) |
3300 |
|
App/Dep Angle(°) |
19/12 |
F/R Suspension(mm) |
1032/1638 |
|
Alex Load(Kg) |
2250/4248 |
Max Speed(Km/h) |
90 |
|
[Chassis Technical Parameters] | ||||
Chassis Model |
EQ1060TJ20D3 |
Chassis Brand |
DONGFENG |
|
Overall Dimension(mm) |
5820×1940×2080 |
Tyre No. |
6 |
|
App/Dep Angle(°) |
19/15 |
Tyre Specification |
7.00-16 |
|
Spring Leaf No. |
8/9+5 |
Front Track(mm) |
1506 |
|
F/R Suspension(mm) |
1032/1488 |
Rear Track(mm) |
1442 |
|
Emission Standard |
Euro Ⅲ |
Fuel Type |
Diesel |
|
Engine Model |
CY4102-C3F |
Engine Brand |
Chao Chai |
|
Power |
95hp/70kw |
Displacement(ml) |
3856 |
|
Steering Wheel |
Left Hand Drive |
Gearbox |
5 speed forward and 1 reverse |
|
[Superstructure Parameters] | ||||
Dust Tank Volume(L) |
3500 |
Tank Material |
Stainless Steel |
|
Water Tank Volume(L) |
800 |
Brushes No. (set) |
4 |
|
[Price] | ||||
The price of road sweeper truck based on the chassis model, engine power, the delivery port and other information. Please let me know your requirement before get the latest price. | ||||
ISO Certificate
More trucks we manufacture
1. Water Tanker/Sprinkler Truck/Pesticide Spraying Truck/Dust Removable Truck
2. Garbage Truck/Garbage Compactor/ Sealed Garbage Truck/ Skip Loader/ Self-loader/ Butt-type Garbage Truck/ Hook Loader
3. Sewage Suction Truck/Fecal Suction Truck/ Sewer Cleaning Truck
4. Aerial Working Truck/ Crane Truck
5. Road Wrecker
6. Road Sweeper
7. Oil tanker/ Refuelling Truck
8. LPG Storage Tanker
9. Chemical Liquid Tanker
10. Bulk Cement Tanker
11. Milk Transport Truck
12. Concrete Mixer/ Concrete Pump Truck
13. Tractor Head
14. Asphalt Distributor
15. Fire Fighting Truck
16.Van Truck/ Refrigerator Truck/ Explosion Proof Truck
17. Mobile Stage Truck/ LED Advertising Truck
18. Dump Truck/ Tipper
19. Feed Delivery Truck
20. Semi-trailer/ Flatbed Semi-trailer/ Container Semi-trailer/ Skeleton Semi-trailer/ Low flatbed Semi-trailer/Stake Semi-trailer/LPG tanker Semi-trailer
Normally, the packaging of our trucks are nude by container or road transport. If by ro-ro ship or bulk carrier ship, it will be covered with wax to prevent corrosion by seawater.
