dongfeng high pressure road sweeper
- 50 Set / Sets per Month
- any port in Shanghai
- T/T
- FAW 4x2 6 wheel 16cbm machanical road sweeper trucks
- Shacman X9 4x2 road cleaning truck sweeper
- Sinotruk howo road sweeper truck 10cbm 12cbm
- Isuzu 700P diesel engine sweeper truck japan road sweeper truck
- Foton 4x2 mini 6 wheel broom sweepers truck 2800 liters
- Dongfeng KINLAND 6x4 6x6 price of road sweeper truck
Product Details
Condition: | New | Place of Origin: | Hubei, China | Brand Name: | CLW |
Dimension(L*W*H): | 8586*2490*2980 | Weight: | 16000kg | Certification: | ISO |
Warranty: | 12 Months | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
1. Technical parameters of road sweeper .
dongfeng high pressure road sweeper
ITEM | UNIT | PARAMETER | |
Vehicle |
| Dongfeng road sweeper | |
Overall dimensions | mm | 8586x2490x2980 | |
Water tank volume | m3 | 9 | |
Dust tank volume | m3 | 7 | |
GVW | kg | Appro×20800 | |
Curb weight |
| Appro×11650 | |
Payload |
| Appro×9000 | |
Wheel base | mm | 5000 | |
F/R track base |
| 1880/1860 | |
F/R suspension |
| 1430/2160 | |
Minimum Ground Clearance | mm | 275 | |
Approach/departure angle | ° | 20/15 | |
Max speed | km/h | 90 | |
Axle Load | kg | 7000/13800 | |
Tire specification | 9.00R20 | Number of axles | 2 |
Steering | Power | Transmission | 6F&1R |
Cab passenger | 3 | Electric System | 24V |
Engine model | Type | Dongfeng Cummins EQB170 33 | |
| Emission level | Emission level | |
| Max.power | 125KW at 2500rpm | |
| Max.torque | 560N.m at 1300rpm | |
| Number of cylinders | 6 | |
| Displacement | 5.9 lit | |
| Cylinder bore | 102 mm | |
| Stroke | 120 mm |
More pictures for your reference:
2. Our service
We are manufacturer engaged in all kinds of special truck, pressure vessel(LPG ).
(1) Over 3000 workers include our sales and engineers will offer you the best design, price, quality;
(2) Pefect after-sales service, offer long days quality guarantee
3. Company introduce
We are professional manufacturer for many kind of special trucks. If this kind of truck don't meet the demand of what you want, make free to let us know you details requirements, we would like to have a further discuss hence offer you the best price and quality!
4. Company strength
In 2013, our factory was honored to be named China‘s top 500 private manufacturing enterprises as 392th. We are looking forward to build a long and successful partnership with you in the near future.
5. Contact us
Thanks for your patience and hope we could have a further communicate about this.
