mechanical broom sweeper truck
The mechanical broom sweeper is also called road sweeper, sweeper truck. Our sweeper truck divided into three classes, one is normal truck mounted with 4 brushes, second is the truck mounted with brushes and sucking disc, third one is rpure sucking road sweeper which means the truck mounted only sucking disc.
Following is the technical parameters for mechanical broom sweeper truck
Main Technical Parameter | ||||
Product Name |
Sweeper Truck |
Gross Vehicle Weight(kg) |
9400 |
|
Curb Weight (kg) |
5705 |
Overall Dimension(mm) |
6700x2290x2500 |
|
Rated Payload(kg) |
3500 |
Cab Allowed Persons |
3 |
|
Axle No. |
2 |
Wheelbase (mm) |
3800 |
|
Chassis Technical Parameter | ||||
Chassis Model |
EQ1090T9ADJ3AC |
Chassis Name |
Truck Chassis |
|
Chassis Brand |
Dongfeng |
Manufacturer |
Dongfeng Automobile Co., Ltd |
|
Overall Dimension (mm) |
6695×2285×2350 |
Tyre No. |
6 with 1 spare tyre |
|
App./ Dep. Angle(º) |
22/13 |
Tyre Spec. |
8.25-16 |
|
Leaf Spring No. |
11/9+7 |
Front Track (mm) |
1831 |
|
Fuel Type |
Diesel |
Rear Track (mm) |
1640 |
|
Drive Type |
4x2 |
Brake System |
Air brake |
|
Steering Type |
Circulate ball |
Gear Box |
5 speed forward and 1 reverse |
|
Engine Technical Parameter | ||||
Engine Model |
CY4102-E3C |
Emission Standard |
Euro III |
|
Displacement ( ml) |
3856 |
Power (KW) |
91 |
|
Cylinder No. |
4 in line |
Engine Type |
Water cooling, four stroke, inter-cooling charged, |
|
Pictures of truck mounted sweeping machine
broom for dust sweeping
Nozzle for water sprinkling
More information of truck mounted sweeping machine, please don't hesitate to let Ms.Amie Nie know by calling at +0086-13872889770
CCC Cerfitication of this CLW5090TSL3 truck mounted sweeping machine
The sweeper truck workshop
More trucks we offer
Contact Us
If you are interested in milk transport truck and other trucks, please feel free to contact with me, tel 0086 13407176512
