ISO LPG Container Pressure Vessel ,ISO LPG Tank Container,ISO Container Gas Storage Tank

ISO LPG Container Pressure Vessel ,ISO LPG Tank Container,ISO Container Gas Storage Tank photo-1
ISO LPG Container Pressure Vessel ,ISO LPG Tank Container,ISO Container Gas Storage Tank photo-2
ISO LPG Container Pressure Vessel ,ISO LPG Tank Container,ISO Container Gas Storage Tank photo-3
ISO LPG Container Pressure Vessel ,ISO LPG Tank Container,ISO Container Gas Storage Tank photo-4
ISO LPG Container Pressure Vessel ,ISO LPG Tank Container,ISO Container Gas Storage Tank photo-5
US$ 10,000 - 50,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Hubei, China
Brand Name:
CLW
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or other port
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Hubei, China
Brand Name CLW
Model Number CLW
Dimension(L*W*H) customized
Capacity customized
Weight customized
After-sales Service Provided Engineers available to service machinery overseas

ISO LPG container Pressure Vessel ,ISO LPG tank container,ISO container gas storage tank

LPG,liquid pressure gas,which is made from oil.The main gas is propane,Isobutane.
Currently our company produce the lpg tank, lpg tank trailer,lpg tank truck to loading and transporting.
The LPG tank volume from 5~120 m3 for above ground, 5~100 m3 for underground.
The LPG tank trailer volume from 30~60 m3 with two axles or three axles.
The LPG tank truck with the volume from 5~35 m3.
ISO LPG container Pressure Vessel ,ISO LPG tank container,ISO container gas storage tank
 ISO LPG container Pressure Vessel ,ISO LPG tank container,ISO container gas storage tank
Main specification

ISO LPG container Pressure Vessel ,ISO LPG tank container,ISO container gas storage tank

product

40 ft LPG container

Design pressure

1 MPa

Max pressure

1.61Mpa

Tank Dimension

Φ 2350 x6x11750 (diameter*material thick* tank length)

Whole Dimension

12191*2438*2591mm

GVW

20.20T

Loading weight

33.75T

Tank Volume

45 cubic meter

Design temperature

30 °C

Tank material

Q345B,carbon steel

Corrupt thick

1mm

Water Testing

2.22 Mpa

Air Testing

1.77 Mpa

Standard

International container design



Factory photo show

ISO LPG container Pressure Vessel ,ISO LPG tank container,ISO container gas storage tank

ISO LPG container Pressure Vessel ,ISO LPG tank container,ISO container gas storage tankISO LPG container Pressure Vessel ,ISO LPG tank container,ISO container gas storage tank

Materials rolled into tank,  Q345R, Q370R, 16MnIII,

ISO LPG container Pressure Vessel ,ISO LPG tank container,ISO container gas storage tank

Water Pressure testing.

ISO LPG container Pressure Vessel ,ISO LPG tank container,ISO container gas storage tank

Tank heating testing room.

ISO LPG container Pressure Vessel ,ISO LPG tank container,ISO container gas storage tankISO LPG container Pressure Vessel ,ISO LPG tank container,ISO container gas storage tank

X-ray testing for the tank side cover welding.

-----------------------------------------------------------

Manufacturer Standard:  GB150,  China.  which is stricter than ASME standard.

We also could produce the product according the ASME standard.
