1-200cbm LPG Storage Tanks
1-200cbm LPG Storage Tanks
1-200cbm LPG Storage Tanks
| Parameters | ||||
| Products name | 1-200cbm LPG Storage Tanks | |||
| Filling medium | LPG(propane) | |||
| Filling weight | 23940kg | |||
| Volume | 60m3 | |||
| Designing pressure | 1.77Mps | |||
| Thickness of cylinder design | 13.7mm | |||
| Thickness of head design | 13.67mm | |||
| Net weight | 12750kg | |||
| Tank size(inner diameter*thickness*length) | DN2700*14*10962mm | |||
| Material of tank | Q345R | |||
| Corrosion allowance | 1mm | |||
| Heat treatment method | Stress-relief heat treatment | |||
| Filling ratio | 0.95 | |||
| Hydraulic test pressure | 2.22Mps | |||
| Life expectancy | 15years | |||
| Medium density (temperature) | 420kg/m3 (50°C) | |||
| Input and output | ||||
| Liquid input Port | DN50 ( 2 Inch) | 2.5Mpa | ||
| Liquid Output Port | DN80 (3 Inch) | 2.5Mpa | ||
| Bottom Air gas input Port x2 | DN50 (2 Inch) | 2.5Mpa | ||
| Waste Liquid Output Port | DN80 (3 Inch) | 2.5Mpa | ||
| Top Gas Let Out Port | DN80 (3 Inch) | 2.5Mpa | ||
| Liquid Level Indicator Port | DN20 | 2.5Mpa | ||
| Standard |
GB150 Steel pressure vessel, pressure vessel safety technology to monitor the procedures |
|||
| Accessory | 1.Safety valve | |||
| 2.Magnetic flap liquid levelgauge gauge | ||||
| 3.Pressure guage | ||||
| 4.Thermometer | ||||
| 5.Cut-off vavels | ||||
--- Packing: Waxed or nude, and covered with tarpaulin.
--- Shipping: small type can be shipped in 20"GP,40"GP,or 40"HQ, big type can be
shipped in bulk ship or RO-ROshipping, or according to your requirement.
1.You are factory or trading Company?
We are a leading manufacture of pressure vessels,bobtails,trailers, trucks, and skid mounted stations,and spare parts. Welcome to visit us in Suizhou city, the production base of Chinese special purpose vehicles.
2.Could you customize exactly according to my requirements?
Yes. We have professional R&D team, we can produce the product exactly according to your requirements.
3. Do you provide certification that we need?
We can provide various certifications associate. Such as BV,DOT, ADR, SASO and so on.
4. What service can I get from you?
We provide lifelong tracking service and one year free warranty for all of our products. Meanwhile we provide free training and technical support to guide you repair your product. If need, we will also send original spare parts free of charge by air.
