SINOTRUK HOWO 4x2 Foam Fire Truck 8m3
Product Notes:
1 SINOTRUK 4*2 two-row chassis,266hp
2 Extinguishing Media:water and foam,8m3
3 Good price
4 High quality
Main parameter of SINOTRUK HOWO 4x2 Foam Fire Truck 8m3
Main Technical Parameter | |||
Product Name |
SINOTRUK Foam Fire Truck |
Overall Dimension(L*W*H)(mm) |
8785×2490×3350 |
Wheelbase(mm) |
4600 |
Tanker volume( m3) |
Water tank:6.2, foam tank:1.8 |
F/ R suspension(mm) |
1500/2685 |
|
|
Curb weight(kg) |
10550 |
Number of Axles |
2 |
Approach/ departure angle (° ) |
25/15 |
Max Speed (km/h) |
85 |
Cab capacity |
2+4 |
Cab Type |
Flat proof, two row |
Chassis parameter | |||
Chassis Model |
ZZ1167M4617C |
Chassis manufacturer |
CNHTC |
Gear Box |
HOWO 10shift |
Transmission type |
Manual |
Steering Type |
LHD with Power Steering |
Traction Type |
4*2 |
Brake System |
Air brake |
Number of Tire |
6 with a spare |
Leaf Spring number |
10/9+6 |
Tire size/type |
11.00-20,11.00R20 |
Engine parameter | |||
Engine Model |
WD615.92 |
Engine manufacturer |
CNHTC |
Fuel type |
diesel |
Displacement(ml) |
9726 |
Emission stand |
Euro 3 |
Power(kw) |
196(266hp) |
Operation System |
Electrically Hydraulic Control |
Electric system |
24V |
Superstructure Equipment & Performance |
1.equipped CB10/60 fire pump(rear)(diversion time≤35s) |
||
2.Water tanker volume: 6m3, tanker material: high quality carbon steel | |||
3.equipped with PS50 type fire monitor,(pressure:1.0MPa,flow:50L/s,shot range≥60m,rotation angle: left or right 360°,up or down-30°~80°) | |||
4.cab type: two-row, steel structure | |||
5 steel pump room/equipments box ,5-9 Aluminum curtain door | |||
6 other equipment: 1600mm long rows of lights in the top of cab | |||
Warranty |
12 months, from the date of supply |
||
More picture of SINOTRUK HOWO 4x2 Foam Fire Truck 8m3 :
Other Brand Foam Fire Truck show as the following:
Our Certificates:
Our production equipments:
Contact Information:
The above information is just for your reference, if you have any other questions or need more truck picture or detailed information, please feel free to contact with me via e-mail or phone, I will try my best to help you. You can count on me. Please check my contact information as below
