SINOTRUK HOWO 4x2 Foam Fire Truck 8m3
Product Notes:
1 SINOTRUK 4*2 two-row chassis,266hp
2 Extinguishing Media:water and foam,8m3
3 Good price
4 High quality
Main parameter of SINOTRUK HOWO 4x2 Foam Fire Truck 8m3
Main Technical Parameter | |||
Product Name | SINOTRUK Foam Fire Truck | Overall Dimension(L*W*H)(mm) | 8785×2490×3350 |
Wheelbase(mm) | 4600 | Tanker volume( m3) | Water tank:6.2, foam tank:1.8 |
F/ R suspension(mm) | 1500/2685 |
|
|
Curb weight(kg) | 10550 | Number of Axles | 2 |
Approach/ departure angle (° ) | 25/15 | Max Speed (km/h) | 85 |
Cab capacity | 2+4 | Cab Type | Flat proof, two row |
Chassis parameter | |||
Chassis Model | ZZ1167M4617C | Chassis manufacturer | CNHTC |
Gear Box | HOWO 10shift | Transmission type | Manual |
Steering Type | LHD with Power Steering | Traction Type | 4*2 |
Brake System | Air brake | Number of Tire | 6 with a spare |
Leaf Spring number | 10/9+6 | Tire size/type | 11.00-20,11.00R20 |
Engine parameter | |||
Engine Model | WD615.92 | Engine manufacturer | CNHTC |
Fuel type | diesel | Displacement(ml) | 9726 |
Emission stand | Euro 3 | Power(kw) | 196(266hp) |
Operation System | Electrically Hydraulic Control | Electric system | 24V |
Superstructure Equipment & Performance | 1.equipped CB10/60 fire pump(rear)(diversion time≤35s) | ||
2.Water tanker volume: 6m3, tanker material: high quality carbon steel | |||
3.equipped with PS50 type fire monitor,(pressure:1.0MPa,flow:50L/s,shot range≥60m,rotation angle: left or right 360°,up or down-30°~80°) | |||
4.cab type: two-row, steel structure | |||
5 steel pump room/equipments box ,5-9 Aluminum curtain door | |||
6 other equipment: 1600mm long rows of lights in the top of cab | |||
Warranty | 12 months, from the date of supply | ||
More picture of SINOTRUK HOWO 4x2 Foam Fire Truck 8m3 :
Other Brand Foam Fire Truck show as the following:
Our Certificates:
Our production equipments:
Contact Information:
The above information is just for your reference, if you have any other questions or need more truck picture or detailed information, please feel free to contact with me via e-mail or phone, I will try my best to help you. You can count on me. Please check my contact information as below
