4*2 DONGFENG Water/foam Fire Truck 3 ton
Water/foam Fire Truck , also known as a firetruck, is used exclusively as extinguishing or other emergency rescue vehicle Fire truck is currently most main tool for fire deprtments to fight fire , and is the most basic mobile firefighting equipment. According to the different types of extinguishing media, fire truck can be divided into water tank fighting truck, foam fighting truck, dry powder fighting truck, etc. We can manufacture kinds of fighting truck from 0.5ton to 22ton, and we also can manufacturer rescue Fire truck, communication command truck, inflatable Fire truck. etc.
Product Notes:
1 DONGFENG 4*2 light chassis,95hp
2 Volume: 3 ton
3 Factory direct sale
4 High quality, competitive price
Main parameter of 4*2 DONGFENG Water/foam Fire Truck 3 ton
Main Technical Parameter | |||
Product Model |
DONGFENG Water/foam Fire Truck |
Overall Dimension(L*W*H)(mm) |
6260×1900×2750 |
Wheelbase(mm) |
3300 |
tanker volume(m3) |
3m3 water tank or 3m3( water tank plus foam tank) |
Curb weight(kg) |
3870 |
Number of Axles |
2 |
Steering Type |
LHD |
Max Speed (km/h) |
90 |
Cab capacity |
2+3 |
Cab Type |
Dongfeng two row cab, |
Chassis Parameter | |||
Chassis Model |
EQ1050NJ20D3 |
Chassis manufacturer |
DONGFENG Automobile Co., Ltd |
Gear Box |
DONGFENG 5 shift |
Transmission type |
Manual |
Brake System |
air brake |
Traction Type |
4*2 |
Number of tire |
6 with a spare |
Tire size/type |
7.00-16 |
Engine parameter | |||
Engine Model |
CY4102-C3F |
Engine manufacturer |
DONGFENG Chaoyang Diesel Engine Co., Ltd |
Fuel type |
diesel |
Displacement(ml) |
3856 |
Emission stand |
Euro 2 |
Power(kw) |
70(95hp) |
Operation System |
Electrically Hydraulic Control |
Electric system |
24V |
Superstructure Equipment & Performance |
1.Equipped with CB10/20 fire pump(middle-loading)(diversion time≤35s)E |
||
2.Water tanker volume:3m3, tanker material: 4mm high quality carbon steel | |||
3.equipped with PS20 type fire monitor,(pressure:1.0MPa,flow:20L/s,shot range≥45m,rotation angle: left or right 360°,up or down-30°~80°) | |||
4.cab type: two-row, steel structure | |||
5 Equipped with steel pump room/equipments box ,5-7Aluminum curtain door, | |||
6 Equipped with one 360° rotation 1100mm long rows of lights in the top of cab | |||
7. Equipped with 8 reel fire fighting water pipe and other necessary special equipments | |||
Warranty |
12 months, from the date of supply |
||
Product picture of 4*2 DONGFENG Water/foam Fire Truck 3 ton :
Other Brand of Water / foam Fire Truck show as the following:
Our Certificates:
Our production equipments:
Contact Information:
The above information is just for your reference, if you have any other questions or need more truck picture or detailed information, please feel free to contact with me via e-mail or phone, I will try my best to help you. You can count on me. Please check my contact information as below
