6*2 Dongfeng Kinland Stake Truck 11-20Ton
6*2 Dongfeng Kinland Stake Truck 11-20Ton
Product Notes:
1 Dongfeng 210hp
2 Factory sale,quality assurance
3 High quality, low price
4 Load 11-20ton
Main Technical Parameter | |||
Product Model |
Dongfeng Kinland Stake Truck |
Overall Dimension(L*W*H)(mm) |
11990×2500×3900 |
Wheelbase(mm) |
1950+5350 |
Compartment Dimension(L*W*H)(mm) |
9400*2294*800 |
F/ R suspension(mm) |
1460/3230 |
Front/Rear tread(mm) |
1980/1980,1860 |
Gross weight (kg) |
Approx 20200 |
Number of Axles |
3 |
Actual Payload(kg) |
Approx9970 |
Fact volume(m3) |
17-20 |
Curb weight(kg) |
10100 |
F/R axle load(Kg) |
4600/4600/11000 |
Approach/ departure angle (° ) |
30/18 |
Max Speed (km/h) |
90 |
Cab capacity |
3 |
Cab Type |
Dongfeng Kingland cab |
Chassis Model |
DFL1203A |
Chassis manufacturer |
Dongfeng Motor Co., Ltd |
Gear Box |
9 shift |
Transmission type |
Manual |
Steering Type |
Power steering |
Traction Type |
6*2 |
Frame type |
Side rails and riveted construction |
Rear axle |
Dongfeng Dena |
Brake System |
Air brake |
||
Leaf Spring number |
8/8/9+9,8/8/8+8,3/3/4+3 |
Tire size/type |
11.00-20 16PR,11.00R20 16PR, |
Engine Model |
ISDe210 30
|
Engine manufacturer |
Dongfeng |
Fuel type |
diesel |
Displacement(ml) |
6700 |
Emission stand |
Euro 3 |
Power(kw) |
155(210hp) |
Warranty |
12 months, from the date of supply |
||
More picture of DONGFENG Stake Truck show as following :
