Help CenterSide Dumper Wagon
Related Products
-
Railway Flat WagonUS$ 80,000 - 90,000MOQ: 5 Sets -
Special Flat Wagon for Prefabricated BridgeUS$ 130,000 - 150,000MOQ: 5 Sets
-
Railway Soda Tank WagonUS$ 100,000 - 110,000MOQ: 5 Sets
-
Railway Sulfuric Acid Tank WagonUS$ 100,000 - 110,000MOQ: 5 Sets
-
Oepn Top WagonUS$ 90,000 - 100,000MOQ: 5 Sets
Specifications
side dumper wagoncomply with various international standards
design and manufacture according to buyer's requirement
Main dimensions:
Length over head stocks 13134±20mm
Length of underframe 12196±10mm
Length between bogie pivot centers 8686±8mm
Width (Maximum) 3325±20mm
Height (Maximum) 2462±20mm
Inside length of carbody upside 11230±20mm
downside 11020±20mm
Inside width of carbody upside 2820±20mm
downside 2626±20mm
Height of floor from rail top 1574±20mm
Height above rail level to underframe center sill height (unloaded) 1163±10mm
Bogie wheel base 1750mm
Wheel diameter 840mm
Height above rail level to bogie pivot center 692mm
Height above rail to center of coupler (unloaded) 880±10mm
Performance parameters
Loading Capacity 60t
Tare Weight 34t
Axle Load 25t
Volume 27 m3
Load per meter of track 7.2 t/m
Equivalent length 1.2
Pressure of cylinder 500 kPa
Volume of air cylinder 0.75 m3
Turnover angle 45°
Speed (maximum) 80km/h
Gauge 1435mm
Minimum Radius of Curvature 80m
Clearance is submitted to GB146.1-1983’ the Clearance for Standard Gauge railway’ and the clearance dimensions indicated in following Drawing
