100T billet flatcar
100T hot-rolled billet flatcar is designed and manufactured by us. Its underframe is the riveted and welded structures of all steel, normally working under the high temperature. It is mainly used to carry hot-rolled billets for large steel mill, and also carries other goods.
It has the advantages of heavy duty, high strength and high impact load stress. Being equipped with insulated-cover, it can resist and withstand the baking of hot-rolled billets up to 1100.
Main specifications
Loading capacity (t) 100
Tare weight (t) 29.3
Axle-load (t) 32.5
Bogie fixed distance between axles (mm) 1820
Height from top of rail to coupler center (mm) 880
Track gauge (mm) 1435
Min radius of curvature (m) 80
Design speed (km/h) 40
