Help CenterAumatic Coir Jute Sisal Plastic Endless Rope Braiding Making Machine
Related Products
-
Make Flax Twisted 2 In 1 Jute Hemp Twine Rope Making MachineUS$ 1,000 - 10,000MOQ: 1 Set -
South Korea Hemp Twine Making Rope Twisted MachineUS$ 1,000 - 10,000MOQ: 1 Set
-
3 Strand Polypropylene Rope Making Machine for Security and Military Nets UseUS$ 1,000 - 10,000MOQ: 1 Set
-
China Mainland New Technology Climbing Coir Jute Sisal Plastic Dual Rope Stranding Making Machinery for Mooring Braided RopeUS$ 1,000 - 10,000MOQ: 1 Set
-
Flax Yarn Manila Twine South Korea Hemp Rope Making MachineUS$ 1,000 - 10,000MOQ: 1 Set
leading Manufacturer PP/HDPE Monofilament Strand Rope Making Machine
Performance and Characteristics:
Your satisfaction is our huge motivator!
1. Natural or man-made fiber all can be used in our rope making machine.
2. It can produce coils length from 440-4890m.
3. It can produce or process the three-strand and four-strand ropes.
4. The machine can do twisting into multi-strand and rope making in one time.
5. High production speed , extremely high output.
6.PLC and touch screen control
Model No |
M44 |
M55 |
M66 |
M77 |
M88 |
EM |
Rope range |
3-10mm |
4-16mm |
8-20mm |
10-25mm |
25-46mm |
3-10mm |
Flyer speed |
0-max,1200 rpm, depending on pre-twist factor |
0-max.900 rpm, depending on pre-twist factor |
0-max.450 rpm, depending on pre-twist factor |
0-max.360 rpm, depending on pre-twist factor |
0-max.300 rpm, depending on pre-twist factor |
0-max.450 rpm, depending on pre-twist factor |
Rope Lay |
S / Z |
|||||
Twist per minutes |
2 x rope flyer speed |
|||||
Lay length |
ANY, automatic control |
|||||
Pre-twist factor |
ANY, automatic contro |
|||||
Take-up, coiling head |
Ø 420 mm, adjustable traverse max. 300 mm, barrel Ø135 mm
|
Ø 480 mm, adjustable traverse max. 345 mm, barrel Ø135 mm
|
Ø 670 mm, adjustable traverse max. 400 mm, barrel Ø210 mm |
Ø 900 mm, adjustable traverse max. 525 mm, barrel Ø260 mm
|
Ø 1000 mm x 600mm, adjustable traverse max.600 mm, barrel Ø260 mm
|
Any |
Take-up, max. weight |
Polypropylene 20 kg |
Polypropylene 40 kg |
Polypropylene 70 kg |
Polypropylene 170 kg |
Polypropylene240 kg,Polyester 430kgs,PP 240KGS,PET430kg |
Any |
plastic rope making machines Plastic Extruders
rope making machinery production line Plastic Extruders
Pre-sales services
* Any concerns of our machine by email/phone will be replied ASAP within 24 hours
* Inquiry and consulting support
* Sample testing support
* View our factory
After-sales service
*Traning how to install the machine ,tranning how to use the machine
*Engineers are avaiable to service machinery overseas
*One year guarantee for the machine expect the spare part ,we can supply lifelong technology service to slove any problem form you .
1. Q: Are you a factory or trading company? How many people work in your company?
A: We are a factory .Wenzhou Ebey machine manufacture co.,ltd is a professional maufactuer of rope making machine line to make different kinds of rope ,auto cutting and sewing machine for pp woven sack,printing machine ,reycling machine etc and now we have more than 100 years till this year .
2. Q: Where is your factory located? How can I visit there?
A: Our factory is located in Wenzhou City, Zhejiang Province, China, about 10 minutes from Aojiang train station and 1 hour from Wenzhou airport. It’s very convenient.
3. Q: Why choose us ?
A: Ablity: we are the first company who realize full automatic system on rope production line (contain yarn making machine ,twisting machine and rope making machine etc .) in China.
4. Q: How does your factory do regarding quality control?
A: Quality is priority." We always attach great importance to quality controlling from the beginning to the end. We have our own R&D department for researching new technology and improve machine .Our factory has passed ISO9001:2000 and we have got CE certificate for our machine .
5. What's your machine's after service ?
A: We have very good after sales service: After you purchase our machine we will send our engineer to your factory to install the machine and train your worker.But our machine is easy to operate ,because our machines are full automatic control by PLC and touch screen ,normally don't need our enginner to install and debug the machine ,it can save much time and money.
