Specifications
1) dia.1000 mm fan blade2) Green solar energy power
3) 32000CMH (18823CFM) air flow
4) DC fan motor
Solar Powered Large-scale industrial ventilation fan specification
| Fan Blade | 1000mm |
| Solar Panel | 300watt |
| Motor | 36 Volt Brushless DC Motor |
| Motor Speed | 420 RPM |
| Air Flow | 32000CMH (18823CFM) |
| Pressure | 60 Pa |
| noise | low than 70dB |
| fan host size | 1100*1100*370mm |
| solar panel size | 1956*992*50mm |
| groos weight | 91 KGS |
CUSTOM SERVICES
additional Mains Switch Controller to change power suppply from solar panel to city electricity for product to work continuously in cloudy or night periods( add 8m cable to connect solar panel with exhaust fanhost)
Product Characteristics & Functions:
1) Clean & Free Solar Energy powered, No commercial electronic consumption.
2) Once Pay, Benefit Long!
3) Cut off conventional monthly boring electricity bills.
4) No manual operation, No maintenance!
5) Value-Added, will pay itself back for you soon after one year.
6) High Quality, Prospective Innovation!
Our advantages / innovations from existing industrial exhaust fans:
1. Direct solar panel power supply, No need of commercial electricity!
2. Flexible Tailor-Make Service, can add a Mains Switch Controller into product to hybrid use the solar panel supply and public electricity supply to have the ventilating fans work continuously after dark or in cloudy periods.
3. Brushless DC fan motor, less energy loss, smaller consumption of commercial electricity than conventional AC motored ventilating fans.
4. Intelligent Mains Switch Mechanism between solar panel supply and public electricity supply, automatically realized by the Mains Switch Controller.
Standard Model Selections:
How are the fans pay themselves back for you after one year?
We offer Tailor-Make Service, simply tell us your requirements and we'll help you to turn all kinds regular electric industrial fans into cost-free solar exhaust fans!
The related solar large scale industrial ventilation fan
| Model | SN2013018 | SN2013019 | SN2013021 | SN2013022 | SN2013023 |
| Fan blade | 500mm | 710mm | 1000mm | 1250mm | 1400mm |
| solar panel | 150 watt | 200watt | 300 watt | 360 watt | 500 watt |
| Motor | 24 V brushless DC motor | 36 V brushless DC motor | |||
| Motor speed | 875RPM | 450 RPM | 420RPM | 420 RPM | 420 RPM |
| Air Flow | 16000CMH | 20000CMH | 32000CMH | 39000CMH | 46000 CMH |
| Pressure | 60 Pa | 60Pa | 65Pa | 56Pa | 60Pa |
| Noise | low than 65 dB | low than 65 dB | low than 70 dB | low than 70 dB | low than 70 dB |
| Fan host size | 620*620*370mm | 800*800*370mm | 1100*1100*370mm | 1380*1380*370mm | 1530*1530*370mm |
| Solar panel size | 1480*670*30mm | 1482*992*50mm | 1956*992*50mm | 2*(1580*808*40mm) | 2*(1800*992*50mm) |
| Gross Weight | 43kgs | 56kgs | 91kgs | 124kgs | 165kgs |
If you want to know more about our solar exahust fan, please feel free to contact us !!!!!
