Home > Products > Negative Pressure Solar Fan > Solar Ventilation fan Wall Mount Greenhouse/ Cow house Negative Pressure Exhaust Fan
Solar Ventilation fan Wall Mount Greenhouse/ Cow house Negative Pressure Exhaust Fan
- 2000 Set / Sets per Month
- Jiangmen
Product Details
Electric Current Type: | DC | Blade Material: | Other, steel | Mounting: | Wall Fan |
Place of Origin: | Guangdong, China | Brand Name: | SIPL | Model Number: | SN2013021 |
Power: | 300 watt solar panel | Air Volume: | 26000CMH (15200CFM) | Speed: | 8m/s |
Certification: | Other | After-sales Service Provided: | No overseas service provided |
Product Description
Solar Powered Large-scale industrial ventilation fan specification
SN2013021:
Fan Blade | 950mm |
Solar Panel | 300watt |
Motor | 24 Volt Brushless DC Motor |
Motor Speed | 420 RPM |
Air Flow | 26000CMH (15200CFM) |
Pressure | 60 Pa |
noise | low than 70dB |
fan host size | 1060*1060*400mm |
solar panel size | 1956*992*50mm |
groos weight | 91 KGS |
CUSTOM SERVICES
additional Mains Switch Controller to change power suppply from solar panel to city electricity for product to work continuously in cloudy or night periods( add 8m cable to connect solar panel with exhaust fanhost)
Product Characteristics & Functions:
1) Clean & Free Solar Energy powered, No commercial electronic consumption.
2) Once Pay, Benefit Long!
3) Cut off conventional monthly boring electricity bills.
4) No manual operation, No maintenance!
5) Value-Added, will pay itself back for you soon after one year.
6) High Quality, Prospective Innovation!
Our advantages / innovations from existing industrial exhaust fans:
1. Direct solar panel power supply, No need of commercial electricity!
2. Flexible Tailor-Make Service, can add a Mains Switch Controller into product to hybrid use the solar panel supply and public electricity supply to have the ventilating fans work continuously after dark or in cloudy periods.
3. Brushless DC fan motor, less energy loss, smaller consumption of commercial electricity than conventional AC motored ventilating fans.
4. Intelligent Mains Switch Mechanism between solar panel supply and public electricity supply, automatically realized by the Mains Switch Controller.
Standard Model Selections:
How are the fans pay themselves back for you after one year?
We offer Tailor-Make Service, simply tell us your requirements and we'll help you to turn all kinds regular electric industrial fans into cost-free solar exhaust fans!
If you want to know more about our solar exahust fan, please feel free to contact us !!!!!
Contact Us
- Jiangmen Sunny Photoelectricity Technology Limited
- Contact nameCindy Fong
- Phone86-0750-6219188
- AddressShagang Industrial Zone of Sanjiang Town, Xinhui District Jiangmen,Guangdong
