Specifications
Concret vibrating table1.Double motor design
2.Customized dimension
3.Noise level less than60dB
4.Energy saving
Concret vibrating table
Vibrating table features
1.In the working process, By adjusting the vibrating force, the material can realize a ideal type
2.Vibration model: up to down, screw vibration and dimensional vibration
3.The table surface and bottom shelf are wholly welded by steel plate and section steel
4.Have magnetic automatically once power on, and haven't magnetic once power off
Technical parameter
Model | Dimesnion (mm) | Motors (sets) | Exciting force(KN) | Power (kw) | Weight (kg) | Amplitude (mm) | Frequency(HZ) |
ZP-2 | 500*500 | 2 | 10 | 1.0 | 300 | 2-5 | 50-60 |
ZP-4 | 800*800 | 2-4 | 20 | 1.5 | 450 | ||
ZP-6 | 1000*1000 | 2-6 | 30 | 2.2 | 600 | ||
ZP-6-2 | 1200*1200 | 4-6 | 30 | 2.2 | 860 | ||
ZP-8-1 | 1600*1200 | 4-6 | 40 | 3.0 | 1000 | ||
ZP-8-2 | 1600*1400 | 4-8 | 50 | 3.0 | 1250 | ||
ZP-10-1 | 2000*1600 | 4-8 | 60 | 4.0 | 1600 | ||
ZP-10-2 | 2000*1800 | 6-10 | 80 | 6.0 | 2000 | ||
ZP-12-2 | 3000*2000 | 6-10 | 80 | 7.5 | 3100 | ||
ZP-12-2 | 4000*3000 | 8-12 | 80 | 7.5 | 4600 |
Application scope
Vibrating table is widely used in selection of Tin, tungsten, gold, silver, lead, zinc, tantalum, niobium, iron, manganese, ferrotitanium and coal. Our company has long history of table concentrator production
