Flour rotary sifter screen machine
- 30 Set / Sets per Month
- Tianjin / Shanghai / Qingdao
- T/T
- wheat flour vibroscreen
- rotary vibrating screen for 24 mesh wheat flour
- Xinxiang Gaofu vibro sifter for wheat powder
- Gaofu high output SZS series single deck vibrating screen for wheat flour
- Food grade vibro screen machine for flavors
- remove impurities vibrating sieve for starch/wheat flour/milk/additive
Product Details
Place of Origin: | Henan, China | Brand Name: | Gaofu | Model Number: | DZ-800 |
Packaging Details
wooden case , standard exporting packing .
Product Description
Flour rotary vibratory inpurity machine
If you are still concerns in your products for the filtration problems, please click on me, and I will you recommended a filter sieve for you, to help you solve your problem of filtering;
Features of vibrating sieve machine:
1. Compact, light weight, mobility,
2. Low noise and pollution,
3. Less energy consumption and easy installation.
4. The machine outlet can be connected to any direction. Sieved material can be discharged straight away, suitable for automated operation.
5. No blockage on screen, high efficiency, applicable for 400 mesh or finer.
Introduction
DZ series vibration sieveis a new-type screening machine, using a single horizontal vibration motor, discharges the materials directly, having a greater handling capacity. It is used in screening granules and powders of flour, starch, detergent, metal powder, additive, chemicals, non-mining industries etc. roughly, precisely. All products contact parts are made of stainless steel, elegant design and durable, small dimension, save space and easy to move.
Automation, the 24 hours of continuous production.
Design of ultra-low-mute, Seal stringent, liquid does not leak; the powder will never be soared. It is easy to clean up the internal and external, non-health corner, meeting with food-grade GMP standards.
Function of vibrating sieve machine:
1. Classification
Each of our products can screen and separate precisely and continuously, the Multi-layer type can screen and separate five groups of different particles at a time. It is suitable for dry materials.
2. Filtrating
The mixture of solid and liquid can be separated effectively by single or multi-layer type into different grade materials.
3. Remove the impurities
Our equipment can quickly separate a few oversize or undersize particles from a quantity of materials.
Daily maintenance:
1. before running
(1) To check coarse mesh and fine mesh if there is damage
(2) Each group clamps is locking.
2. Running
(1) Notice any abnormal noises
(2) Electric current is stable
(3) Whether the vibration is abnormal.
3. after running
(1) After used clean up the vibration every time
(2) To inspect regularly the coarse mesh, fine mesh and the spring if there are fatigue and damage
(3) Whether each part of the vibrating body caused damage due to vibration.
(4) Need to add the site to be the lubricating oil
Technical parameters
Model | Power (kw) | Motor speed (r/min) | Sieve diameter (mm) | Dimension(mm) | Wight(kg) |
DZ-600 | 0.18 | 1450 | 580 | 1000*600*550 | 200 |
DZ-800 | 0.25 | 1450 | 780 | 1100*800*600 | 250 |
DZ-1000 | 0.55 | 1450 | 960 | 1280*1000*700 | 330 |
DZ-1200 | 0.75 | 1450 | 1160 | 1550*1200*750 | 400 |
DZ-1500 | 1.5 | 1450 | 1460 | 1850*1500*900 | 750 |
Note:
1. Material: SUS 304 / Q235A / 316 L.
2. Voltage: 380V /400V.
3. Voltage: 380V /400V, Frequency:50 / 60 HZ.
4. If the specification or appearance has changed, we will not notify additionally.
The picture of machine's Working principle structure :
Our Company:
Our company has more than 30 years experience in machinery manufacturing industry , so We can provide you professional free technical service.
We ever exported this machine to America , Australia , Canda , Chile , Trinidad , and Tobago , Peru , Ghana and so on .And the perfect quality of the machine acquire many my customers` great praise .
Our company has passed the ISO9001:2008 Quality system certificate , and obtained the CE certificate.
Company Profile
Xinxiang Gaofu Sieving Machinery Co., Ltd. specializes in manufacturing vibration screens and vibrating sieves. To solve sieving problems in all fields, we can manufacture all kinds of vibrating screens to meet the different needs of customers.
Thanks to production equipment, strong technical capabilities, improved detection means and strict managing system, we have enjoyed good reputation.
our company has attained ISO9001:2000 certification and CE Certification. Our products sell well throughout China and are exported to North America, West Europe, Southeast Asia and other countries and regions.
Do you want to improve your product quality? Do you want your products to become more competitive? Choosing Xinxiang Gaofu Sieving Machine Co., Ltd.! We will be your friend in the way to success! And you will create a shiny future in 2014!
Please visit our website: www.gaoful.com.
Our tenet: "Honest Service, the Highest Quality".To solve sieving problems in all fields, we can manufacture all kinds of vibrating screens to meet the different needs of customers.
