High Frequency Mechanical Sieve Shaker

Xinxiang Gaofu Machinery Co., Ltd. Gold Verified Supplier
5Yrs
High Frequency Mechanical Sieve Shaker thumbnail-1
High Frequency Mechanical Sieve Shaker thumbnail-2
High Frequency Mechanical Sieve Shaker thumbnail-3
High Frequency Mechanical Sieve Shaker thumbnail-4
High Frequency Mechanical Sieve Shaker thumbnail-5
High Frequency Mechanical Sieve Shaker thumbnail-6
High Frequency Mechanical Sieve Shaker photo-1
High Frequency Mechanical Sieve Shaker photo-2
High Frequency Mechanical Sieve Shaker photo-3
High Frequency Mechanical Sieve Shaker photo-4
High Frequency Mechanical Sieve Shaker photo-5
High Frequency Mechanical Sieve Shaker photo-6
US$ 400 - 10,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Linear
Application:
Other, stainless steel wire sieving
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao/Tianjin/Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Linear
Application Other, stainless steel wire sieving
Place of Origin Henan, China
Brand Name Gaofu
Model Number SZF-1540-3S-Q235A
Voltage 220V/380/415V or others
Power(W) 3.7*2KW
Dimension(L*W*H) 4500*1750*1600MM
Weight 3300KG
Certification CE/SO9001:2008/BV/SGS
Warranty 12 month
After-sales Service Provided Engineers available to service machinery overseas

  High Frequency Mechanical Sieve Shaker



1. Description



SZF series mechanical sieve shaker use vibration motor as vibration source, the materials is rosed and moved in the straight at the same time. The materials are entered into entrance equality, and then go through screen to create the materials with different sizes, which was discharged, from different gates. It is suitable for low consuming, high output, and simple structure, easily maintain all-closed structure, no powder dispersed, automobile discharged.



2. Application:



SZF series mechanical sieve shaker is specialed for Blast furnace coal injection process



3.  Advantage:



Transact certificate of origin

Authentication of invoice

Authentication of fumigation



4. Technical Parameter:



Model

Size(mm)

Material size(mm)

Inclination

Amplitude(mm)

Layer

Power(KW)

SZF-520

500×2000



























0.074-10



























0-7 degree



























4-10



























1-6 layer

2*(0.4-0.75)

SZF-525

500×2500

2*(0.4-0.75)

SZF-1020

1000×2000

2*(0.4-0.75)

SZF-1025

1000×2500

2*(0.4-1.1)

SZF-1030

1000×3000

2*(1.1-1.5)

SZF-1040

1000×4000

2*(1.1-1.5)

SZF-1235

1000×3500

2*(1.1-2.2)

SZF-1250

1200×5000

2*(1.1-2.2)

SZF-1535

1500×3500

2*(1.1-2.2)

SZF-1560

1500×6000

2*(2.2-3.7)

SZF-1845

1800×4500

2*(2.2-3.7)

SZF-2050

2000×5000



0.074-15

2*(2.2-3.7)

SZF-2260

2200×6000

2*(2.2-3.7)





5. Different materials Screen frame:





High Frequency Mechanical Sieve Shaker

6. details of machine:



High Frequency Mechanical Sieve Shaker



 7. Customer site

 High Frequency Mechanical Sieve Shaker
