Linear vibrating sieve machine for sand
It can help you wipe out the impurities in the powder !
It can make various types of material classification according to your requirements !
It is widely used for sieving fine particles and mealiness materials in building material, abrasive , chemical industry, metallurgy ,chemical fertilizer.
Why can it be done ?
Please see the following schematic diagram :
1. introduction:
SZF series linear vibrating sieve machineuse vibration motor as vibration source, the materials is rosed and moved in the straight at the same time. The materials are entered into entrance equality, and then go through screen to create the materials with different sizes, which was discharged, from different gates.
Inlets, outlets and legs can be custom fit to your installation requirements
- Linear sieveFeatures/Description:
- High output.
- simple structure
- easy maintenance.
- low energy consumption
- small noise
- full-enclosed structure
- high screening efficiency
- long life
- energy saving , hing efficiency
- passed ISO 9001:2008
- Linear Sieve Technical parameters :
Model | Size(mm) | Inclination | Amplitude(mm) | Layer | Power(KW) |
SZF-520 | 500×2000 |
0-7 degree |
4-10 |
1-6 layer | 2*(0.4-0.75) |
SZF-525 | 500×2500 | 2*(0.4-0.75) | |||
SZF-1020 | 1000×2000 | 2*(0.4-0.75) | |||
SZF-1025 | 1000×2500 | 2*(0.4-1.1) | |||
SZF-1030 | 1000×3000 | 2*(1.1-1.5) | |||
SZF-1040 | 1000×4000 | 2*(1.1-1.5) | |||
SZF-1235 | 1200×3500 | 2*(1.1-2.2) | |||
SZF-1250 | 1200×5000 | 2*(1.1-2.2) | |||
SZF-1535 | 1500×3500 | 2*(1.1-2.2) | |||
SZF-1560 | 1500×6000 | 2*(2.2-3.7) | |||
SZF-1845 | 1800×4500 | 2*(2.2-3.7) | |||
SZF-2050 | 2000×5000 | 2*(2.2-3.7) | |||
SZF-2260 | 2200×6000 | 2*(2.2-3.7) |
Note:
1. Each type can be 1-5 layers, and the mesh size is from 0.1 to 30mm.
2. Material: Q235A / SUS 304 / 316L
3. Voltage: 380V /400V, Frequency: 50 / 60 HZ.
4. If the specification or appearance has changed, we will not notify additionally.
Our Screen frame has two types: different screen frame structures, help you get more quality screening purpose!
1. Stainless steel screen frame
2. If you use this wooden screen frame, the price will be more favorable
Product ' detail :
GAOFU company have a perfect after-sales service system and professional technology team to provide you with prompt and thorough service. Our price are more competitive and reasonable, each order will be supplied within the stipulated period.
Delivery Process :
I will provide you the following convenient :
Transact certificate of origin
Authentication of invoice
Authentication of fumigation
