SZF series linear vibrating screen
SZF Series linear vibrating screenis low consuming, high output, simple structure, easy,maintain, no powder dispersed, automobile discharged. It can be used universally for test screening or to produce between 2 and 4 screen fractions. A good screening effect is achieved by the circular vibration in the vertical plane.
Effect demo figure
SZF Series linear vibrating screen are very useful in plastics, rubber, ceramic, food, pharmaceutical, chemical, fertilizer, glass industries. Vibratory screens can be provided with dust proof cover as required. SZF Series linear vibration screen can be supplied of different sizes depending upon capacity required. They can also handle slightly wet material.
Make the order: Inlets, outlets and legs can be custom fit to your installation requirements.
Model | Size(mm) | Material size(mm) | Inclination | Amplitude(mm) | Layer | Power(KW) |
SZF-520 | 500×2000 | 0.074-10 | 0-7 degree | 4-10 | 1-6 layer | 2*(0.4-0.75) |
SZF-525 | 500×2500 | 2*(0.4-0.75) | ||||
SZF-1020 | 1000×2000 | 2*(0.4-0.75) | ||||
SZF-1025 | 1000×2500 | 2*(0.4-1.1) | ||||
SZF-1030 | 1000×3000 | 2*(1.1-1.5) | ||||
SZF-1040 | 1000×4000 | 2*(1.1-1.5) | ||||
SZF-1235 | 1000×3500 | 2*(1.1-2.2) | ||||
SZF-1250 | 1200×5000 | 2*(1.1-2.2) | ||||
SZF-1535 | 1500×3500 | 2*(1.1-2.2) | ||||
SZF-1560 | 1500×6000 | 2*(2.2-3.7) | ||||
SZF-1845 | 1800×4500 | 2*(2.2-3.7) | ||||
SZF-2050 | 2000×5000 |
0.074-15 | 2*(2.2-3.7) | |||
SZF-2260 | 2200×6000 | 2*(2.2-3.7) |
Screen frame:
Different screen frame structure, help you get more quality screening purpose!
1. Stainless steel screen frame
2. wooden screen frame
3. Vibrating motor
